Airtac MU Mini Free Mount Cylinder MU10X30S
1. Compliant with JIS B8377 standards;
2. Four-directional mounting options with tool-free installation;
3. Space-optimized clustered configuration capability;
4. Integrated alignment boss ensures precise positioning;
5. Hard-anodized precision-bored barrel with exceptional wear/corrosion resistance;
6. Optional magnetic piston for position feedback;
7. T-slotted body accommodates proximity sensors with flexible mounting;
8. Asymmetrical bidirectional sealing system with integrated lubrication reservoir.
Category: Free Mount Cylinders | Brand: AirTAC | Series: MU
AirTAC MU Series Miniature Free Mount Cylinder MU10X30S Technical Details
- Model: MU10X30S
- Type: Double-acting cylinder with magnetic piston
- Bore size: 10mm (0.39")
- Stroke: 30mm (1.18") ±0.5mm tolerance
- Operating pressure: 0.05–0.9 MPa (7-130 PSI)
- Ambient temperature: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer (both ends)
- Mounting style: Free position (non-repairable design)
- Port size: M5x0.8 (standard) with 6mm push-in fittings
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel SUS304
- Seals: NBR rubber (standard), optional FKM for high temp
- Weight: 0.15kg (0.33lbs)
- Dimensions: 70mm(L) × 25mm(W) × 25mm(H)
- Protection class: IP40 (dust protected)
- Max speed: 500mm/s (with cushion)
- Theoretical force: 7.85N at 0.5MPa (extending)
Ultra-compact cylinder optimized for space-critical automation systems. Features a low-friction design achieving over 3,000km service life at 0.3MPa. The magnetic piston enables position feedback when paired with external sensors (sensor not included). Anti-rotation design maintains orientation during operation.
- PCB handling robots in electronics manufacturing
- Precision valve actuation in medical analyzers
- Cartesian coordinate pick-and-place systems
- Semiconductor wafer clamping mechanisms
- Automated test equipment positioners
Installation best practice:
Apply thread locker (Loctite 243 recommended) on mounting screws.
Maintain 0.5-1mm clearance between magnetic sensor and cylinder body.
Lubricate with ISO VG32 hydraulic oil if used in vertical orientation.
| Property | Property Value |
|---|---|
| sku | MU10X30S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | 30mm |
