Airtac MU Mini Free Mount Cylinder MU10X30SB
1. Compliant with JIS B8377 standards;
2. Four-directional mounting options with tool-free installation;
3. Space-optimized clustered configuration capability;
4. Integrated alignment boss ensures precise positioning;
5. Hard-anodized precision-bored barrel with exceptional wear/corrosion resistance;
6. Optional magnetic piston for position feedback;
7. T-slotted body accommodates proximity sensors with flexible mounting;
8. Asymmetrical bidirectional sealing system with integrated lubrication reservoir.
Category: Free Mount Cylinders | Brand: AirTAC | Series: MU
AirTAC MU Series Miniature Free Mount Cylinder MU10X30SB Specifications
- Model: MU10X30SB
- Type: Double-acting cylinder with magnetic piston
- Bore size: 10mm (0.39")
- Stroke: 30mm (1.18")
- Operation: Air pressure dual action
- Working pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Cushioning: Rubber buffer (both ends)
- Mounting style: Free mounting (no fixed bracket)
- Port size: M5×0.8 (standard) with 6mm push-in fittings
- Magnetic sensor: Built-in magnet for position detection
- Piston rod material: Hard chrome-plated carbon steel
- Seal material: NBR (Nitrile) with grease retention design
- Protection rating: IP40 (dust protected)
- Weight: 0.12kg (0.26lbs)
- Dimensions: 80mm(L) × 20mm(W) × 20mm(H) (3.15"×0.79"×0.79")
Ultra-compact pneumatic cylinder optimized for space-constrained automation systems. Features precision honed aluminum alloy tube with wear-resistant coating and self-lubricating bushings. The SB variant includes magnetic piston for sensor compatibility and symmetrical air ports for flexible piping. Requires 5μm filtered air with ISO VG32 hydraulic oil mist lubrication (1 drop/cycle recommended).
- PCB handling robots in electronics manufacturing
- Micro-dosing valves in medical devices
- Precision clamping mechanisms for CNC tooling
- Automated test equipment positioners
- Compact packaging machine actuators
Installation note:
Maximum side load 3N. For vertical mounting, use anti-rotation guides.
Allow 2mm clearance around cylinder body for thermal expansion. Lubricate
through air supply (oil-less operation requires special seals).
| Property | Property Value |
|---|---|
| sku | MU10X30SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | 30mm |
