Airtac MU Mini Free Mount Cylinder MU10X4S
1. Compliant with JIS B8377 standards;
2. Four-directional mounting options with tool-free installation;
3. Space-optimized clustered configuration capability;
4. Integrated alignment boss ensures precise positioning;
5. Hard-anodized precision-bored barrel with exceptional wear/corrosion resistance;
6. Optional magnetic piston for position feedback;
7. T-slotted body accommodates proximity sensors with flexible mounting;
8. Asymmetrical bidirectional sealing system with integrated lubrication reservoir.
Category: Free Mount Cylinders | Brand: AirTAC | Series: MU
AirTAC MU Series Miniature Free Mount Cylinder MU10X4S Specifications
- Model: MU10X4S
- Type: Single-acting spring return (push type)
- Bore size: 10mm (φ10)
- Stroke: 4mm ±0.5mm
- Operating pressure: 0.05–0.7 MPa
- Port size: M5x0.8 (standard) with 6mm push-in fitting
- Cushioning: Rubber buffer
- Piston rod thread: M5x0.8 external thread
- Mounting style: Free installation (no fixed mount bracket)
- Ambient temperature: -10℃ to 60℃
- Cylinder material: Aluminum alloy body, CRMo steel piston rod
- Seal material: NBR rubber
- Weight: 0.12kg ±3%
- Dimensions:
- Total length (L): 47mm (at retracted position)
- Cylinder outer diameter: 16mm
- Rod end dimensions: 12mm(W) × 12mm(H)
Ultra-compact pneumatic cylinder designed for space-constrained automation systems. Features precision ground piston rod (Ra≤0.4μm surface roughness) and dual-purpose mounting grooves allowing direct fixture integration. The anodized aluminum construction provides corrosion resistance in humid environments. Requires 5μm filtered air with ISO VG32 turbine oil mist lubrication (1 drop/m³ recommended).
- PCB handling robots for micro-component positioning
- Medical device sample tray indexing mechanisms
- Semiconductor wafer inspection equipment actuators
- Compact valve switching in beverage dispensing systems
- Precision clamping in watch assembly jigs
Installation tip:
Utilize the 360° rotatable pneumatic ports for flexible piping layout.
Apply thread locker (medium strength) on mounting screws when
subjected to vibration ≥5G. Maximum side load capacity: 2.5N at full extension.
| Property | Property Value |
|---|---|
| sku | MU10X4S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | <4mm> |
