Airtac MU Mini Free Mount Cylinder MU10X4SB
1. Compliant with JIS B8377 standards;
2. Four-directional mounting options with tool-free installation;
3. Space-optimized clustered configuration capability;
4. Integrated alignment boss ensures precise positioning;
5. Hard-anodized precision-bored barrel with exceptional wear/corrosion resistance;
6. Optional magnetic piston for position feedback;
7. T-slotted body accommodates proximity sensors with flexible mounting;
8. Asymmetrical bidirectional sealing system with integrated lubrication reservoir.
Category: Free Mount Cylinders | Brand: AirTAC | Series: MU
AirTAC MU Series Miniature Free Mounting Cylinder MU10X4SB Specifications
- Model: MU10X4SB
- Type: Single-acting spring return (push type)
- Bore size: 10mm
- Stroke: 40mm (standard)
- Operating pressure: 0.05–0.9 MPa
- Port size: M5x0.8 (dual ports)
- Cushion type: Fixed rubber bumper
- Temperature range: -10℃ to 70℃
- Piston material: Aluminum alloy (hard anodized)
- Rod material: Stainless steel (SUS304)
- Seal material: NBR rubber
- Mounting type: Free (no dedicated bracket)
- Weight: 85g ±2%
- Dimensions:
- Body diameter: Φ20mm
- Total length: 98mm (at full retraction)
- Port spacing: 16mm center-to-center
- Rod thread: M4x0.7 (external)
- Protection rating: IP57 (dust resistant & limited water immersion)
Ultra-compact cylinder optimized for space-constrained automation systems, featuring a unique anti-rotation guide structure for precise linear motion. The chrome-plated piston rod and self-lubricating bushings enable maintenance-free operation. Requires 5μm filtered dry air with ISO 8573-1:2010 Class 3.4.2 air quality.
- PCB handling robots in electronics assembly
- Micro-dosing valves in medical devices
- Precision clamping fixtures for watchmaking
- Optical lens positioning systems
- Laboratory sample tray indexers
Installation note:
Maximum lateral load 3N·m. For vertical mounting,
maintain ≥0.3 MPa pressure to ensure complete return stroke.
Lubricate rod weekly with ISO VG32 turbine oil in high-cycle applications (>500,000 cycles/month).
| Property | Property Value |
|---|---|
| sku | MU10X4SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | <4mm> |
