Airtac MU Mini Free Mount Cylinder MU10X8
1. Compliant with JIS B8377 standards;
2. Four-directional mounting options with tool-free installation;
3. Space-optimized clustered configuration capability;
4. Integrated alignment boss ensures precise positioning;
5. Hard-anodized precision-bored barrel with exceptional wear/corrosion resistance;
6. Optional magnetic piston for position feedback;
7. T-slotted body accommodates proximity sensors with flexible mounting;
8. Asymmetrical bidirectional sealing system with integrated lubrication reservoir.
Category: Free Mount Cylinders | Brand: AirTAC | Series: MU
AirTAC MU Series Miniature Free Mount Cylinder MU10X8 Technical Details
- Model: MU10X8 (MU-10×8)
- Bore size: 10mm (ISO 6432 standard)
- Stroke: 8mm (adjustable cushioning)
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5×0.8 (dual pneumatic ports)
- Piston speed: 50–800 mm/s (lubricated)
- Buffer type: Rubber cushion (both ends)
- Mounting options: Side/Flange/Foot (accessories sold separately)
- Material: Aluminum alloy cylinder tube, SUS304 piston rod
- Seal material: NBR (nitrile rubber)
- Weight: 0.08kg ±3% (bare cylinder)
- Dimensions: 72mm(L) × 20mm(W) × 20mm(H) (standard mount)
- Rod end thread: M5×0.8 (male)
- Max theoretical force: 6.28N (at 0.8MPa)
- Repeat positioning accuracy: ±0.2mm
The MU10X8 represents AirTAC's ultra-compact cylinder solution for precision linear motion. Featuring dual-position sensing slots (compatible with magnetic sensors) and multi-directional mounting flexibility, this 10mm bore cylinder delivers exceptional responsiveness in confined spaces. The anodized aluminum construction ensures corrosion resistance while maintaining lightweight performance.
- PCB handling robots in electronics assembly
- Micro-dispenser actuation in medical devices
- Precision clamping in watchmaking jigs
- Paper feed mechanisms in compact printers
- Valve control in portable analytical instruments
Installation notes:
For optimal performance, maintain 0.5–1mm clearance between cylinder body and mounting surface to prevent thermal expansion interference. Use only AirTAC PUN series fittings (PUN-4M) for leak-free connections. Lubricate with ISO VG32 hydraulic oil if operating below -10℃.
Critical parameters:
Maximum side load capacity 2.5N·m, axial torsion limit 0.8N·m. Requires 5μm filtered air. Not suitable for vertical rod-down orientation without external guide mechanisms.
| Property | Property Value |
|---|---|
| sku | MU10X8 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <8mm> |
