Airtac NPM Clamp Cylinder NPM45T63X13AIL
2、Cylinder barrels undergo precision surface treatments to significantly enhance wear resistance and corrosion durability;
3、Integrated spindle air purge functionality for enhanced machining cleanliness.
Category: Tool Clamping Cylinders | Brand: AirTAC | Series: NPM
AirTAC NPM Series Knife Edge Cylinder NPM45T63X13AIL Specifications
- Model: NPM45T63X13AIL
- Type: Compact double-acting knife edge cylinder
- Bore size: Ø63mm
- Stroke: 13mm (adjustable cushion)
- Mounting style: Fixed centerline (IL-type flange)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -10℃ to 80℃
- Port size: M5x0.8 (dual ports)
- Cushioning: Adjustable elastic buffer
- Piston rod thread: M12x1.25
- Material: Aluminum alloy body, CR12MoV hardened blade
- Weight: 0.95kg ±5%
- Dimensions: 175mm(L) × 63mm(W) × 63mm(H)
- Seal material: Heat-resistant NBR + PTFE coating
- Repeat accuracy: ±0.05mm
- Protection rating: IP54 (standard)
Precision-engineered compact cylinder featuring hardened knife-edge blade for accurate positional locking. Optimized for high-frequency reciprocation (up to 3Hz) with wear-resistant guide surfaces. Includes integrated shock absorption and anti-rotation mechanism. Requires ISO 8573-1:2010 Class 3 compressed air.
- CNC tool changer clamping mechanisms
- Semiconductor wafer handling robots
- Precision stamping die positioning
- Printing press roller engagement systems
- Food packaging flap sealing actuators
Installation note:
Lubricate with ISO VG32 hydraulic oil mist lubrication (1-2 drops/m³).
Maintain 0.3-0.6 MPa operating pressure for optimal blade engagement.
Avoid side-load exceeding 15N during operation.
| Property | Property Value |
|---|---|
| sku | NPM45T63X13AIL |
| Output Force | Output Force 4500kg |
| Micro Switch | 2 Micro Switches |
| Blade Stroke | 13mm |
| Port Size | PT3/8 |
| Standard Voltage | AC220V |
| Hydraulic Cylinder Bore | 63mm |
