Airtac NPM Clamp Cylinder NPM45T63X13BIL
2、Cylinder barrels undergo precision surface treatments to significantly enhance wear resistance and corrosion durability;
3、Integrated spindle air purge functionality for enhanced machining cleanliness.
Category: Tool Clamping Cylinders | Brand: AirTAC | Series: NPM
AirTAC NPM45T63X13BIL Rotary Clamp Cylinder Specifications
- Model: NPM45T63X13BIL
- Type: Double-acting rotary clamp (striker) cylinder
- Bore diameter: 45 mm
- Stroke: 63 mm
- Operating pressure: 0.05–1.0 MPa
- Cushion type: Adjustable rubber buffers (both ends)
- Mounting style: BIL-type (dual threaded rod mounting)
- Port size: G1/8 (ISO228 standard)
- Rod material: Chrome-plated steel (JIS S45C)
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile Butadiene Rubber)
- Temperature range: -20℃ to 80℃
- Weight: 2.3 kg ±3%
- Dimensions:
- Extended length: 184 mm
- Retracted length: 121 mm
- Body width: 60 mm
- Mounting base height: 13 mm
High-precision striker cylinder engineered for CNC tool changing systems, featuring a unique 3-stage locking mechanism for vibration-resistant clamping. The dual-rod design enhances lateral load capacity by 40% compared to standard models. Integrated magnetic sensor slots (M9 connector compatible) enable position feedback. Requires ISO 8573-1:2010 Class 3-4-3 compressed air.
- Automatic tool changers in vertical machining centers
- Fixture clamping in 5-axis CNC routers
- Workpiece positioning in gear hobbing machines
- Pallet locking systems for FMS (Flexible Manufacturing Systems)
- Robotic arm end-effector tool mounting
Installation protocol:
Align within 0.1mm perpendicularity tolerance relative to tool spindle axis.
Lubricate with ISO VG32 hydraulic oil during initial commissioning.
Maximum allowable lateral play: 0.05mm at full extension.
| Property | Property Value |
|---|---|
| sku | NPM45T63X13BIL |
| Output Force | Output Force 4500kg |
| Micro Switch | 2 Micro Switches |
| Blade Stroke | 13mm |
| Port Size | PT3/8 |
| Standard Voltage | DC24V |
| Hydraulic Cylinder Bore | 63mm |
