Airtac RMS Magnetic Coupling Rodless Cylinder RMS32X200
$256.79
Regular price
$264.29
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
RMS32X200
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Magnetic coupling rodless cylinder with no mechanical connection between piston and slider, offering excellent sealing performance;
2. Piston movement transmitted to external slider via magnetic coupling force, eliminating piston rod requirements - features reduced installation space compared to standard cylinders while achieving longer maximum stroke;
3. Integrated adjustable cushioning at both ends with fixed cushioning mechanisms ensures smooth directional changes without impact shock, effectively preventing mechanical damage;
4. Isolation design between piston chamber and slider prevents contaminant ingress, significantly prolongs service life of the cylinder.
Category: Rodless Cylinders , Brand: AirTAC , Series: RMS
Installation note:
Maintain 0.5mm minimum clearance between magnetic band and sensors.
Lubricate guide rails with ISO VG32 hydraulic oil during initial setup.
Avoid lateral impact forces exceeding 50N during operation.
2. Piston movement transmitted to external slider via magnetic coupling force, eliminating piston rod requirements - features reduced installation space compared to standard cylinders while achieving longer maximum stroke;
3. Integrated adjustable cushioning at both ends with fixed cushioning mechanisms ensures smooth directional changes without impact shock, effectively preventing mechanical damage;
4. Isolation design between piston chamber and slider prevents contaminant ingress, significantly prolongs service life of the cylinder.
Category: Rodless Cylinders , Brand: AirTAC , Series: RMS
AirTAC RMS32X200 Magnetic Coupling Rodless Cylinder Specifications
- Model: RMS32X200
- Type: Magnetic coupling rodless cylinder (non-rotating design)
- Bore size: 32mm
- Stroke length: 200mm
- Operating pressure: 0.1–0.8 MPa
- Temperature range: -20℃ to 80℃
- Piston speed: 50–800 mm/s
- Maximum load capacity: 200N (horizontal), 150N (vertical)
- Seal material: NBR (standard), optional FKM
- Mounting style: Dual rail-guided with 4 mounting slots
- Sensor compatibility: M9/M12 magnetic switches (pre-drilled T-slots)
- Port size: G1/8 (ISO standard)
- Weight: 2.8 kg (excluding accessories)
- Dimensions: 500mm(L) × 82mm(W) × 78mm(H)
- Protection rating: IP54 (standard), IP67 with optional wiper seals
High-precision rodless cylinder using magnetic coupling technology to eliminate external seals and prevent leakage. Features dual linear guides for enhanced moment resistance and T-slot design for easy sensor mounting. The anodized aluminum construction ensures corrosion resistance in humid environments.
Typical Applications:
- High-speed pick-and-place systems in electronics assembly
- Precision material handling in cleanroom environments
- Automated packaging line positioning mechanisms
- Automotive part transfer systems requiring dust-free operation
- Pharmaceutical sorting equipment with frequent stroke changes
Installation note:
Maintain 0.5mm minimum clearance between magnetic band and sensors.
Lubricate guide rails with ISO VG32 hydraulic oil during initial setup.
Avoid lateral impact forces exceeding 50N during operation.
Performance Features:
- Zero-leakage design suitable for vacuum applications
- ±0.5mm repeat positioning accuracy
- Integrated scraper system prevents debris accumulation
- Compatible with ISO 15552 mounting accessories
| Property | Property Value |
|---|---|
| sku | RMS32X200 |
| Mounting Type | Without Mounting Accessories |
| Safety Holding Force N | Stroke: 560mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°F Speed Range: 50-400 mm/s |
| Port Size | PT1/8 |
| Cushion Type | Fixed Cushion |
| Bore Diameter | <32 mm> |
| Stroke | <200mm> |
