Airtac SILF Front Locking Air Cylinder SIF40X150
2. Unlocking methods: Featuring automatic and manual unlocking operation modes.
Category: Locking Cylinders , Brand: AIRTAC , Series: SILF
AirTAC SILF Series Front Lock Cylinder SIF40X150 Technical Specifications
- Model: SIF40X150
- Type: Double-acting with mechanical lock
- Bore size: Ø40mm
- Stroke: 150mm
- Operating pressure: 0.1-0.8 MPa
- Locking mechanism: Spring-activated wedge lock
- Operation direction: Bidirectional locking
- Cushioning type: Adjustable air cushion (both ends)
- Mounting style: Standard MF1 flange mounting (ISO 15552 compatible)
- Port size: M5x0.8 (G1/8 adaptor included)
- Temperature range: -20℃ to 80℃
- Seal material: HNBR (Hydrogenated Nitrile) with wear-resistant guide rings
- Position repeatability: ±0.5mm (under locked condition)
- Protection rating: IP67 (wipers included)
- Weight: 1.85kg ±3% (excluding accessories)
- Dimensions: 250mm(L) × 62mm(W) × 62mm(H) (full extension)
Precision locking cylinder featuring instant position retention capability through its wedge-type mechanical lock mechanism. The anodized aluminum construction with chrome-plated piston rod ensures corrosion resistance in harsh environments. Integrated magnetic sensor slots (T-slot design) enable position feedback when used with compatible sensors.
- Vertical load holding in automated assembly lines
- Safety positioning in press machinery
- Intermediate stop control in material handling systems
- Precision fixturing in semiconductor manufacturing
Installation note:
Engage locking mechanism before system pressurization during installation.
Maintain 0.3-0.5 MPa minimum pressure for reliable unlocking. Lubricate lock
mechanism with ISO VG32 hydraulic oil every 500,000 cycles.
Critical parameters:
Maximum side load capacity 150N at full extension. Do not exceed
0.8m/s piston speed when engaging lock. Requires 5μm filtered air
with automatic drain function.
| Property | Property Value |
|---|---|
| sku | SIF40X150 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | 150mm |
| Lock Position | Front Cover with Lock |
