Airtac SILF Front Locking Air Cylinder SIF40X40
2. Unlocking methods: Featuring automatic and manual unlocking operation modes.
Category: Locking Cylinders , Brand: AIRTAC , Series: SILF
AirTAC SILF Front Lock Cylinder SIF40X40 Technical Details
- Bore size: 40mm (ISO 6432 standard)
- Stroke range: 25-500mm (customizable)
- Operating pressure: 0.15-1.0 MPa
- Locking force: 850N @ 0.5MPa
- Lock mechanism: Wedge-type mechanical lock (manual release option)
- Port size: M5x0.8 (G1/8 adaptor included)
- Cushioning: Adjustable air cushion + shock absorber pad
- Operating temperature: -20℃ to 80℃
- Rod material: Hard chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Seals: HNBR wear-resistant seals
- Weight: 1.65kg (standard 40mm stroke version)
- Dimensions: 178mm(L) × 50mm(W) × 50mm(H) (40mm stroke)
- Protection class: IP54 (standard), IP67 optional
- Mounting options: Front flange, rear pivot, or side mounting
High-precision locking cylinder with fail-safe position retention, featuring dual piston seals and anti-rotation guide rods. The wedge-lock mechanism engages within 0.5° of angular deviation, maintaining position during air pressure loss. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- Vertical load holding in material handling systems
- Safety positioning in press brake tooling
- Precision fixturing for CNC machining centers
- Emergency stop mechanisms in automated assembly lines
- Overhead crane brake systems
Installation protocol:
Lock engagement requires minimum 0.3MPa pressure. Lubricate with ISO VG32 hydraulic oil
before initial use. Avoid side-load forces exceeding 15% of maximum thrust capacity.
| Property | Property Value |
|---|---|
| sku | SIF40X40 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | <40mm> |
| Lock Position | Front Cover with Lock |
