Airtac SILF Front Locking Air Cylinder SIF40X400
2. Unlocking methods: Featuring automatic and manual unlocking operation modes.
Category: Locking Cylinders , Brand: AIRTAC , Series: SILF
AirTAC SILF Series Front Lock Cylinder SIF40X400 Specifications
- Model: SIF40X400
- Type: Double-acting with mechanical front lock mechanism
- Bore size: 40 mm
- Stroke: 400 mm
- Operating pressure: 0.1–1.0 MPa
- Locking force: 1,200 N (at 0.5 MPa)
- Lock release pressure: ≥0.3 MPa
- Piston speed: 50–800 mm/s
- Port size: M5x0.8 (G1/8 adapter optional)
- Buffer type: Adjustable air cushion
- Mounting style: Basic type (MF1)
- Rod end type: Male thread M16x1.5
- Ambient temperature: -20℃ to 80℃
- Material: Aluminum alloy barrel, Chrome-plated piston rod
- Seal material: NBR (standard), optional Polyurethane
- Weight: 3.8 kg (including mounting brackets)
- Dimensions: 558mm(L) × 56mm(W) × 56mm(H) (retracted length)
- Extended length: 958mm (retracted length + stroke)
- Protection class: IP54 (standard wiper seal)
- Lubrication: Pre-lubricated (Grease-free operation available)
High-precision locking cylinder featuring instant position retention capability through its integrated front mechanical lock. The dual-safety design combines pneumatic holding force with physical locking, achieving zero drift during power/pressure loss. Optimized for vertical applications requiring position memory and emergency stop functions.
- Automated welding fixture position locking
- Elevator safety brake actuation systems
- CNC machine tool clamping units
- Overhead material handling systems
- Solar panel tilt adjustment mechanisms
- Packaging line emergency stop stations
Installation notes:
- Lock engagement requires minimum 0.3MPa pressure - install pressure gauge for verification
- Maintain 0.5mm minimum clearance between lock mechanism and mating surface
- For vertical mounting, install drip-proof cover (accessory code: SIF-CAP4)
- Relubricate every 500km of cumulative stroke movement
| Property | Property Value |
|---|---|
| sku | SIF40X400 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | <400mm> |
| Lock Position | Front Cover with Lock |
