Airtac SILF Front Locking Air Cylinder SIF40X450
2. Unlocking methods: Featuring automatic and manual unlocking operation modes.
Category: Locking Cylinders , Brand: AIRTAC , Series: SILF
AirTAC SILF Front Lock Cylinder SIF40X450 Technical Specifications
- Model: SILF-SIF40X450
- Bore size: 40mm
- Stroke: 450mm
- Operating pressure: 0.1-1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushioning type: Adjustable air cushion (both ends)
- Locking mechanism: Dual piston mechanical lock
- Port size: G1/2 (ISO228/1 standard)
- Rod thread: M20×1.5
- Material: Aluminum alloy body, CR12MoV hardened piston rod
- Seal material: NBR + PU combination
- Weight: 3.8kg ±2%
- Dimensions: 595mm(L) × 62mm(W) × 62mm(H)
- Protection rating: IP54 (standard), IP67 (optional)
- Mounting type: Front flange MF1 (ISO15552 compatible)
Heavy-duty locking cylinder with fail-safe position retention, featuring instantaneous mechanical locking at any stroke position through dual interlocking pistons. The chrome-plated piston rod with multi-layer sealing ensures ≤0.5mm position drift under 0.5MPa residual pressure. Requires 5-40μm filtered lubricated air (ISO8573-1 class 4).
- Vertical lifting mechanisms in assembly lines
- Emergency stop position locking in CNC machinery
- Overhead material handling systems
- Press brake tooling positioning
- Automotive welding fixture clamping
Installation note:
Requires periodic lubrication (ISO VG32 hydraulic oil recommended).
Locking force reduces by 15% when installed vertically downward.
Always engage manual release lever during maintenance.
| Property | Property Value |
|---|---|
| sku | SIF40X450 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | 450mm |
| Lock Position | Front Cover with Lock |
