Airtac SILF Front Locking Air Cylinder SIF40X50
2. Unlocking methods: Featuring automatic and manual unlocking operation modes.
Category: Locking Cylinders , Brand: AIRTAC , Series: SILF
AirTAC SILF Front Lock Cylinder SIF40X50 Technical Details
- Model: SILF SIF40X50
- Bore size: 40mm
- Stroke: 50mm
- Operating pressure: 0.05–1.0 MPa
- Locking force: 1,080N (at 0.5MPa)
- Lock type: Mechanical wedge locking (spring applied)
- Port size: G1/8 (ISO228/1 standard)
- Cushioning: Adjustable air cushion
- Piston speed: 50–700mm/s
- Ambient temperature: -10℃ to 70℃
- Seal material: Polyurethane (NBR optional)
- Rod material: Hard chrome-plated steel
- Weight: 2.3kg ±5% (without accessories)
- Dimensions:
- Extended length: 231mm
- Retracted length: 181mm
- Body width: 60mm
- Mounting height: 40mm
- ISO standard: 15552 (formerly ISO6431)
Heavy-duty locking cylinder with instant position hold capability, featuring dual safety mechanisms against accidental release. The wedge-lock design maintains position even during air supply interruption, with precision ground rod surface (Ra≤0.4μm) for smooth operation. Requires 5μm filtered air and regular lubrication (ISO VG32 hydraulic oil recommended).
- Vertical load positioning in CNC tool changers
- Safety clamping in die-casting machinery
- Workpiece retention in automated welding stations
- Emergency stop systems for material handling robots
- Precision alignment fixtures for optical component assembly
Installation guidelines:
Locking mechanism activates only in fully extended/retracted positions.
Allow 0.5-1mm axial play during mounting. Perform weekly lock groove cleaning
in high particulate environments. Not recommended for continuous reciprocating
cycles exceeding 60CPM.
| Property | Property Value |
|---|---|
| sku | SIF40X50 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | <50mm> |
| Lock Position | Front Cover with Lock |
