Airtac SILF Front Locking Air Cylinder SIF40X500
2. Unlocking methods: Featuring automatic and manual unlocking operation modes.
Category: Locking Cylinders , Brand: AIRTAC , Series: SILF
AirTAC SILF Series Front Lock Cylinder SIF40X500 Technical Details
- Model: SIF40X500
- Type: Double-acting pneumatic cylinder with mechanical front lock
- Bore size: Ø40mm
- Stroke: 500mm
- Operating pressure: 0.15–1.0 MPa
- Lock holding force: 1,960N (at 0.5MPa)
- Piston speed: 50–800mm/s
- Cushioning type: Adjustable elastic cushion (both ends)
- Port size: G1/4 (NPT1/4 optional)
- Ambient temperature: -20℃ to 80℃
- Seal material: NBR + Polyurethane
- Protection rating: IP54 (standard rod wiper)
- Weight: 3.5kg ±5%
- Dimensions: 718mm(L) × 58mm(W) × 58mm(H) (extended length)
- Mounting type: Front flange MF1 (ISO 15552 standard)
High-load positioning cylinder featuring instant mechanical locking at stroke end, designed for vertical applications requiring position retention during power loss. The chromium-plated piston rod and anodized aluminum construction ensure durability in humid environments. Requires 5μm filtered air with lubrication (ISO VG32 recommended).
- Elevator safety brake systems
- Automated warehouse vertical lift positioning
- Press machine mid-stroke holding
- Solar panel tilt adjustment mechanisms
- Robotic welding positioner locking
Installation note:
Lubricate lock mechanism weekly with ISO VG32 oil. Maintain minimum 15mm
free space behind cylinder for lock disengagement. Avoid side-load exceeding
50N during operation.
| Property | Property Value |
|---|---|
| sku | SIF40X500 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | 500mm |
| Lock Position | Front Cover with Lock |
