Airtac SR Pressure Regulator SR20006LJN
2、Compact structure with space-saving design for simplified installation;
3、Stable pressure regulation with superior pressure control performance;
4、Available in standard version and low-pressure variant (maximum adjustable pressure 0.4MPa).
Category: Pressure Regulators , Brand: AIRTAC , Series: SR
AirTAC SR Series Pressure Regulator SR20006LJN Technical Specifications
- Model: SR20006LJN
- Type: Precision air pressure regulator with gauge
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure range: 0.05–0.95 MPa
- Maximum flow rate: 3,500 L/min (ANR)
- Pressure adjustment: Knob-type with lock nut
- Body material: Aluminum alloy (anodized finish)
- Seal material: NBR rubber (FDA compliant option available)
- Temperature range: -5℃ to 80℃ (non-freezing)
- Weight: 520g ±2% (without accessories)
- Dimensions: 98mm(H) × 50mm(W) × 45mm(D)
- Gauge range: 0–1.0 MPa (dual scale: MPa & psi)
- Thread torque rating: 15–20 N·m
- Vibration resistance: ≤10 Hz @ 1.5mm amplitude
High-sensitivity pressure regulator featuring dual-chamber design for stable output under fluctuating input pressures. Equipped with a 40mm oversized diaphragm for precise control and rapid response. The built-in silencer reduces exhaust noise to ≤65 dB(A). Includes anti-rotation bracket and tamper-resistant adjustment knob.
- Pneumatic tool pressure stabilization in assembly lines
- Process control systems for semiconductor manufacturing
- Packaging machinery tension regulation
- Medical gas pressure management
- Robotic end-effector pneumatic circuits
- Food processing air knife systems
Installation guidelines:
Mount vertically with arrow aligned to airflow direction. Install downstream filter (5μm)
if input air contains particulates. Perform initial pressure setting at maximum system flow.
Lubrication-free design - do not apply oil to internal components.
| Property | Property Value |
|---|---|
| sku | SR20006LJN |
| Port Size | PT1/8 |
