Airtac SR Pressure Regulator SR200084
2、Compact structure with space-saving design for simplified installation;
3、Stable pressure regulation with superior pressure control performance;
4、Available in standard version and low-pressure variant (maximum adjustable pressure 0.4MPa).
Category: Pressure Regulators , Brand: AIRTAC , Series: SR
AirTAC SR Series Pressure Regulator SR200084 Technical Specifications
- Model: SR200084
- Type: Precision pressure regulator with gauge port
- Port size: PT1/4 (G1/8 gauge interface)
- Operating pressure range: 0.05–0.85 MPa
- Pressure regulation range: 0.05–0.6 MPa
- Max flow capacity: 2,200 NL/min
- Body material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Temperature range: -5℃ to 80℃
- Weight: 450g ±5%
- Dimensions: 55mm(L) × 50mm(W) × 65mm(H)
- Mounting type: Panel mount (bracket included)
- Pressure gauge: Integrated 1/8" NPT threaded port
- Protection rating: IP40
- Hysteresis: ≤0.02 MPa
Industrial-grade pressure regulator featuring zero-leak diaphragm design and precision control knob with lock mechanism. The zinc alloy adjustment handle provides 280° rotation for fine pressure tuning. Includes anti-vibration gauge connector and sintered bronze filter element (replaceable). Compatible with ISO 1/4 BSPP threads.
- Pneumatic conveyor systems pressure stabilization
- CNC machine tool air pressure compensation
- Packaging line actuator pressure control
- Semiconductor manufacturing cleanrooms
- Automotive painting booth pressure management
Installation guidelines:
Mount upstream of lubricators, maintain horizontal orientation for optimal diaphragm performance.
Use 40μm pre-filter when air quality exceeds ISO 8573-1 Class 4. Annual diaphragm inspection recommended.
- CV value: 1.8
- Effective area: 32mm²
- Pressure drop: ≤0.1 MPa at max flow
| Property | Property Value |
|---|---|
| sku | SR200084 |
| Port Size | PT1/4 |
