Airtac SR Pressure Regulator SR20008LJ1
2、Compact structure with space-saving design for simplified installation;
3、Stable pressure regulation with superior pressure control performance;
4、Available in standard version and low-pressure variant (maximum adjustable pressure 0.4MPa).
Category: Pressure Regulators , Brand: AIRTAC , Series: SR
AirTAC SR Series Pressure Regulator SR20008LJ1 Technical Specifications
- Model: SR20008LJ1
- Type: Precision pressure regulator with lockable knob
- Port size: PT1/4 (G1/4 optional)
- Pressure range: 0.05–0.85 MPa
- Max flow capacity: 2000 NL/min
- Adjustment type: Manual rotary control with 360° rotation
- Body material: Anodized aluminum alloy
- Seal material: HNBR (Hydrogenated Nitrile) rubber
- Operating temperature: -10℃ to 80℃
- Weight: 480g ±5%
- Dimensions: 98mm(L) × 52mm(W) × 62mm(H)
- Pressure gauge interface: M5 threaded
- Venting method: Non-bleed type (closed exhaust)
- Mounting orientation: Any position (vertical recommended)
Industrial-grade pressure regulator featuring dual-chamber design for stable output under fluctuating input pressures. The chrome-plated brass diaphragm ensures corrosion resistance, while the ergonomic locking knob prevents accidental adjustments. Includes integrated silencer for reduced exhaust noise (68 dB(A) max). Requires upstream 5μm filtration.
- Pneumatic actuator pressure stabilization
- Assembly line tooling systems
- Packaging machinery tension control
- Medical gas pressure regulation
- Semiconductor handling equipment
Installation note:
Install downstream of lubricator when used with pneumatic tools.
For pulsation-sensitive applications, maintain minimum 300mm
distance from quick exhaust valves. Perform monthly diaphragm
integrity checks in high-cycling environments.
- Pull adjustment knob upward to unlock
- Rotate clockwise to increase pressure (view gauge)
- Push knob downward to lock setting
- Verify stability under load conditions
| Property | Property Value |
|---|---|
| sku | SR20008LJ1 |
| Port Size | PT1/4 |
