Airtac TDH Stop Cylinder TDH20X15L
2. Reinforced piston rod design significantly enhances lateral impact resistance capability;
3. Heavy-duty TDH series features integrated oil cushioning or adjustable hydraulic shock absorbers to reliably absorb kinetic energy during impact;
4. Lever-type roller mechanism incorporates a self-locking device that prevents arm rebound and unintended push-back on blocked objects;
5. Multiple configurations and standardized specifications available for customized application requirements.
Category: Stop Cylinders , Brand: AIRTAC , Series: TDH
AirTAC TDH Series Blocking Cylinder TDH20X15L Technical Details
- Model: TDH20X15L
- Type: Double-acting rodless blocking cylinder
- Bore size: Ø20mm (ISO 6432 standard)
- Stroke: 15mm ±0.5mm
- Operating pressure: 0.05-0.8 MPa
- Temperature range: -10℃ to 70℃
- Cushioning: Elastic buffer + shock absorber pad
- Mounting types: Front flange (MF1), rear flange (MF2), or side mount
- Port size: M5x0.8 (G1/8 adaptor optional)
- Piston rod thread: M6x1 external thread (ISO 12240-1)
- Material: Aluminum alloy cylinder tube, hardened stainless steel guide rod
- Seals: NBR (Nitrile) standard, optional FKM for high temp
- Protection class: IP54 (dust protected & water resistant)
- Weight: 0.42kg ±3% (without accessories)
- Dimensions: 150mm(L) × 42mm(W) × 42mm(H)
Precision rodless cylinder with integrated mechanical locking mechanism, featuring zero-backlash linear motion. The TDH20X15L combines compact footprint (15mm stroke) with 180N maximum thrust force. Dual-slot design prevents rotation during operation. Includes wear-resistant guide bushings and anti-vibration pads for high cycle rates up to 3,000,000 cycles.
- Precision positioning in semiconductor handling robots
- Clamping mechanisms in CNC fixture systems
- Vertical Z-axis motion in SMT component placers
- Part ejection systems in high-speed packaging lines
- Safety interlocks for automated assembly stations
Installation protocol:
Requires perpendicular mounting surface with ≤0.1mm/m flatness.
Lubricate guide rod with ISO VG32 hydraulic oil before initial use.
Avoid side loads exceeding 15N to prevent premature wear.
| Property | Property Value |
|---|---|
| sku | TDH20X15L |
| Port Size | M5×0.8 |
| Proximity Sensor Thread Type | M5×0.5 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <15mm> |
