Airtac TDH Stop Cylinder TDH25X15L
2. Reinforced piston rod design significantly enhances lateral impact resistance capability;
3. Heavy-duty TDH series features integrated oil cushioning or adjustable hydraulic shock absorbers to reliably absorb kinetic energy during impact;
4. Lever-type roller mechanism incorporates a self-locking device that prevents arm rebound and unintended push-back on blocked objects;
5. Multiple configurations and standardized specifications available for customized application requirements.
Category: Stop Cylinders , Brand: AIRTAC , Series: TDH
AirTAC TDH Series Blocking Cylinder TDH25X15L Specifications
- Model: TDH25X15L
- Type: Compact double-acting blocking cylinder
- Bore size: 25mm
- Stroke: 15mm
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: Rc1/8 (NPT1/8 optional)
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal type: NBR (Nitrile) seals
- Weight: 0.65kg ±5%
- Dimensions:
- Body length: 116mm
- Total extended length: 131mm (stroke included)
- Mounting base width: 32mm
- Rod end thread: M10×1.25
- ISO Standard: 6432 (compact cylinder specifications)
- Protection rating: IP54 (standard), IP67 (optional)
High-precision blocking cylinder with integrated mechanical stopper mechanism, featuring a dual-purpose design for both linear motion and positive-position locking. The TDH25X15L combines 0.02mm repeat positioning accuracy with 50,000km+ service life under rated conditions. Its anti-rotation rod design ensures stable workpiece handling, while the dual-sensor slots (front/rear) enable position feedback integration.
- Precision part positioning in PCB assembly lines
- Workpiece rejection systems in packaging machinery
- Tooling fixture locking in CNC automation
- Safety interlocks in automotive welding stations
- Cartesian robot end-effector braking
Installation guidelines:
Mount using M5 fasteners with 28mm center spacing. For vertical installations,
maintain minimum 0.3MPa pressure to prevent gravity-induced drift. Lubricate
rod weekly with ISO VG32 pneumatic oil in high-cycle applications (>2000 cycles/day).
| Property | Property Value |
|---|---|
| sku | TDH25X15L |
| Port Size | M5×0.8 |
| Proximity Sensor Thread Type | M5×0.5 |
| Magnet | Non-magnetic |
| Bore Diameter | <25 mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <15mm> |
