Airtac TDH Stop Cylinder TDH25X15SLF
2. Reinforced piston rod design significantly enhances lateral impact resistance capability;
3. Heavy-duty TDH series features integrated oil cushioning or adjustable hydraulic shock absorbers to reliably absorb kinetic energy during impact;
4. Lever-type roller mechanism incorporates a self-locking device that prevents arm rebound and unintended push-back on blocked objects;
5. Multiple configurations and standardized specifications available for customized application requirements.
Category: Stop Cylinders , Brand: AIRTAC , Series: TDH
AirTAC TDH Series Stopper Cylinder TDH25X15SLF Technical Details
- Model: TDH25X15SLF
- Series: Rod-type double acting cylinder
- Bore size: Ø25mm
- Stroke: 15mm (±1mm tolerance)
- Action type: Dual pneumatic cushioning (adjustable)
- Operating pressure: 0.05-1.0 MPa
- Piston speed: 50-800 mm/s
- Mounting style: Foot-mounted (MF1) with precision alignment grooves
- Port size: M5x0.8 (G1/8 adaptor included)
- Piston rod material: SUS304 stainless steel (hard chrome plated)
- Cylinder tube: Aluminum alloy (hard anodized surface)
- Seal material: NBR + Polyurethane hybrid seals
- Temperature range: -20℃ to 80℃ (dry air required below 0℃)
- Weight: 0.85kg (excluding accessories)
- Dimensions: 115mm(L) × 34mm(W) × 34mm(H) (at fully retracted position)
- Rod end thread: M6×1.0 internal thread
- Repeat positioning accuracy: ±0.1mm
- ISO standard: 6432 compliant
High-precision stopping cylinder with integrated shock absorption, featuring a hardened piston rod and wear-resistant guide bushings. The TDH25X15SLF's compact profile and anti-rotation design ensure stable linear motion, with built-in magnetic sensor slots (inductor not included) for position feedback. Requires 5μm filtered lubricated air (ISO 8573-1 class 3.4.2).
- Precision workpiece positioning in CNC pallet systems
- Carton gate control in high-speed packaging lines
- PCB clamping mechanisms in SMT equipment
- Tooling fixture locks in automotive welding robots
- Component alignment in pharmaceutical blister packaging
Installation guidelines:
Lubricate rod end before initial use. Maintain 0.3-0.5mm clearance between stopper
face and target surface. For vertical mounting, install air vent downward.
Recommended maintenance interval: 3 million cycles or 12 months.
| Property | Property Value |
|---|---|
| sku | TDH25X15SLF |
| Port Size | M5×0.8 |
| Proximity Sensor Thread Type | M5×0.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <25 mm> |
| Self-locking Function | Self-locking |
| Stroke | <15mm> |
