Airtac TDH Stop Cylinder TDH32X20K
2. Reinforced piston rod design significantly enhances lateral impact resistance capability;
3. Heavy-duty TDH series features integrated oil cushioning or adjustable hydraulic shock absorbers to reliably absorb kinetic energy during impact;
4. Lever-type roller mechanism incorporates a self-locking device that prevents arm rebound and unintended push-back on blocked objects;
5. Multiple configurations and standardized specifications available for customized application requirements.
Category: Stop Cylinders , Brand: AIRTAC , Series: TDH
AirTAC TDH Series Blocking Cylinder TDH32X20K Specifications
- Model: TDH32X20K
- Type: Double-acting blocking cylinder with magnetic piston
- Bore size: 32mm
- Stroke: 20mm
- Operating pressure: 0.1–0.8 MPa
- Cushioning type: Adjustable pneumatic cushioning
- Mounting style: Front flange/Foot mount (MF1 standard)
- Port size: M5x0.8 (G1/8 adaptor optional)
- Operating temperature: -20℃ to 80℃
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Chrome-plated steel
- Seal material: NBR (Nitrile rubber)
- Weight: 1.2kg (excluding accessories)
- Dimensions: 100mm(L) × 80mm(W) × 80mm(H) (retracted position)
- Extended length: 120mm (stroke included)
- Repeat accuracy: ±0.5mm
- Max thrust: 200N @ 0.6MPa
High-precision blocking cylinder featuring integrated magnetic sensor slots (inductive sensor not included) and anti-rotation mechanism. The TDH32X20K's dual piston design ensures precise stopping force control with 5-position adjustable cushioning. Corrosion-resistant construction with IP54 protection rating makes it suitable for harsh environments.
- Precision workpiece positioning in CNC machining centers
- Partition control in automated assembly lines
- Safety interlock systems in press machinery
- Load braking in material handling systems
- Tooling fixture clamping in automotive manufacturing
Installation guidelines:
Maintain 0.5mm minimum clearance between cylinder and sensor bracket.
Use AirTAC IS1002 series sensors for optimal magnetic detection.
Lubricate with ISO VG32 turbine oil for initial operation.
Critical notes:
Maximum side load capacity 30N.
Requires 40μm filtered air with oil mist (1/1000 ratio).
Avoid axial impact forces exceeding 150N during operation.
| Property | Property Value |
|---|---|
| sku | TDH32X20K |
| Port Size | PT1/8 |
| Proximity Sensor Thread Type | M5×0.5 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <20mm> |
