Airtac TDH Stop Cylinder TDH32X20KF
2. Reinforced piston rod design significantly enhances lateral impact resistance capability;
3. Heavy-duty TDH series features integrated oil cushioning or adjustable hydraulic shock absorbers to reliably absorb kinetic energy during impact;
4. Lever-type roller mechanism incorporates a self-locking device that prevents arm rebound and unintended push-back on blocked objects;
5. Multiple configurations and standardized specifications available for customized application requirements.
Category: Stop Cylinders , Brand: AIRTAC , Series: TDH
AirTAC TDH Series Blocking Cylinder TDH32X20KF Technical Details
- Model: TDH32X20KF
- Type: Double-acting spring return blocking cylinder
- Bore size: 32mm
- Stroke: 20mm
- Operating pressure: 0.05–0.8 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion
- Port thread: G1/8 (ISO228 standard)
- Piston rod material: Hard chrome-plated steel
- Seal material: NBR (Nitrile rubber)
- Mounting type: Foot-mounted (Standard) with optional flange/bracket kits
- Protection rating: IP54 (standard sealing)
- Weight: 0.82kg (bare cylinder)
- Dimensions:
- Extended length: 170mm
- Retracted length: 150mm
- Body width: 42mm
- Mounting foot height: 18mm
High-precision mechanical blocking cylinder with integrated position-locking mechanism, featuring hardened aluminum alloy construction for industrial durability. The TDH32X20KF combines 0.02mm repeat positioning accuracy with 50,000km service life under rated load. Includes wear-compensation seals and anti-rotation guide slots for stable vertical/horizontal operation.
- Pallet stop systems in automated warehouses
- Workpiece positioning in CNC machining centers
- Conveyor synchronization in packaging lines
- Precision clamping in automotive fixturing
- Carton alignment in food processing machinery
Installation protocol:
Align cylinder axis within ±0.5° of load direction. Apply ISO VG32 hydraulic oil
or equivalent for initial lubrication. Maximum side load capacity: 15N at full extension.
| Property | Property Value |
|---|---|
| sku | TDH32X20KF |
| Port Size | PT1/8 |
| Proximity Sensor Thread Type | M5×0.5 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Self-locking Function | Self-locking |
| Stroke | <20mm> |
