Airtac TDH Stop Cylinder TDH40X30K
2. Reinforced piston rod design significantly enhances lateral impact resistance capability;
3. Heavy-duty TDH series features integrated oil cushioning or adjustable hydraulic shock absorbers to reliably absorb kinetic energy during impact;
4. Lever-type roller mechanism incorporates a self-locking device that prevents arm rebound and unintended push-back on blocked objects;
5. Multiple configurations and standardized specifications available for customized application requirements.
Category: Stop Cylinders , Brand: AIRTAC , Series: TDH
AirTAC TDH Series Blocking Cylinder TDH40X30K Technical Details
- Model Code: TDH40X30K
- Bore Size: 40mm (ISO 6432 standard)
- Stroke: 30mm ±0.5mm tolerance
- Action Type: Single-acting spring return
- Operating Pressure: 0.05-0.9 MPa
- Proof Pressure: 1.35 MPa
- Cushion Type: Adjustable rubber buffer
- Port Size: G1/8 (ISO 228-1)
- Piston Speed: 50-800 mm/s (lubricated)
- Ambient Temp Range: -20℃ to 80℃
- Mounting Type: Basic front flange (MF2)
- Rod Thread: M10×1.25 (external)
- Weight: 0.98 kg ±3%
- Dimensions (L×W×H):
- Retracted: 131mm × 40mm × 40mm
- Extended: 161mm × 40mm × 40mm
- Materials:
- Tube: Aluminum alloy (hard anodized)
- Piston Rod: Chrome-plated steel (HRC 45-50)
- Seals: NBR + PU hybrid
High-precision blocking cylinder with integrated mechanical stopper mechanism, designed for precision positioning and impact absorption in repetitive linear motion systems. Features dual-layer wear-resistant seals and anti-rotation guide slots for stable operation under side load conditions. Requires ISO VG32 hydraulic oil mist lubrication for optimal performance.
- Carton positioning gates in packaging lines
- Workpiece clamping in CNC machining centers
- Elevator door safety interlocks
- Pallet stop mechanisms in AS/RS warehouses
- Press-fit operations in electronic component assembly
Installation guidelines:
Align stopper surface within 0.2mm perpendicularity tolerance.
Apply thread locker (Loctite 243 recommended) on mounting bolts.
Maintain 0.5-1mm clearance between stopper and impact surface.
| Property | Property Value |
|---|---|
| sku | TDH40X30K |
| Port Size | PT1/8 |
| Proximity Sensor Thread Type | M5×0.5 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Self-locking Function | Non Self-locking |
| Stroke | 30mm |
