Airtac TDH Stop Cylinder TDH50X30KF
2. Reinforced piston rod design significantly enhances lateral impact resistance capability;
3. Heavy-duty TDH series features integrated oil cushioning or adjustable hydraulic shock absorbers to reliably absorb kinetic energy during impact;
4. Lever-type roller mechanism incorporates a self-locking device that prevents arm rebound and unintended push-back on blocked objects;
5. Multiple configurations and standardized specifications available for customized application requirements.
Category: Stop Cylinders , Brand: AIRTAC , Series: TDH
AirTAC TDH Series Blocking Cylinder TDH50X30KF Technical Specifications
- Model: TDH50X30KF
- Type: Double-acting single piston rod blocking cylinder
- Bore size: Ø50mm
- Stroke: 30mm (±1mm tolerance)
- Operating pressure: 0.1-0.8 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting style: ISO 15552 standard flange (MF1)
- Port size: G1/8 (BSPP thread)
- Piston material: Aluminum alloy with hard anodizing
- Rod material: SUS304 stainless steel
- Seal type: HNBR (Hydrogenated Nitrile) seals
- Built-in magnet: Yes (For position sensing)
- Ambient temperature: -20℃ to +80℃
- Protection class: IP67 (Dust/water resistant)
- Weight: 2.3kg (without accessories)
- Dimensions: 156mm(L) × 60mm(W) × 60mm(H) (Extended length)
- Retracted length: 126mm
- Rod thread: M16×1.5 (External)
- Lubrication: Pre-lubricated (Grease-free operation)
High-precision blocking cylinder with integrated mechanical lock mechanism, featuring dual-position detection through embedded magnetic system. The TDH series employs a unique wedge-shaped brake structure that achieves 3x greater holding force compared to standard cylinders. Anti-vibration design ensures stable operation at up to 1.5m/s piston speed.
- Precision workpiece positioning in CNC pallet systems
- Safety interlock mechanisms in automotive assembly lines
- Load securing in automated warehousing robots
- Emergency stop systems for material handling equipment
- Process interruption in semiconductor manufacturing
Installation requirements:
Maintain 0.5-1mm clearance between brake surface and load. Use only dry filtered air
(40μm filter, dew point -25℃). For vertical mounting, install rod end downward.
Requires weekly inspection of brake pad thickness (minimum 0.8mm).
Dynamic response time: ≤0.15s (Locking/unlocking)
Repeat positioning accuracy: ±0.2mm
Service life: 5,000km travel distance or 10 million cycles
| Property | Property Value |
|---|---|
| sku | TDH50X30KF |
| Port Size | PT1/8 |
| Proximity Sensor Thread Type | M8×1.0 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Self-locking Function | Self-locking |
| Stroke | 30mm |
