Airtac TDH Stop Cylinder TDH63X30K
2. Reinforced piston rod design significantly enhances lateral impact resistance capability;
3. Heavy-duty TDH series features integrated oil cushioning or adjustable hydraulic shock absorbers to reliably absorb kinetic energy during impact;
4. Lever-type roller mechanism incorporates a self-locking device that prevents arm rebound and unintended push-back on blocked objects;
5. Multiple configurations and standardized specifications available for customized application requirements.
Category: Stop Cylinders , Brand: AIRTAC , Series: TDH
AirTAC TDH Series Stopping Cylinder TDH63X30K Technical Details
- Model: TDH63X30K
- Type: Double-acting rod-type stopping cylinder
- Bore size: 63mm
- Stroke: 30mm
- Operating pressure: 0.05-1.0 MPa
- Cushioning type: Adjustable air cushion (both ends)
- Port size: G1/8 (M5 available as option)
- Ambient temperature: -20℃ to 80℃
- Piston speed: 50-750 mm/s
- Rod material: Hard chrome-plated steel
- Tube material: Aluminum alloy with hard anodizing
- Seal material: NBR (Nitrile rubber)
- Protection class: IP54 (standard), IP67 (optional)
- Weight: 1.65 kg (without accessories)
- Dimensions:
- Length (retracted): 163mm ±1mm
- Width (mounting base): 85mm
- Height (including rod): 115mm
High-precision stopping cylinder with integrated mechanical locking mechanism, featuring dual-position magnetic sensing slots for precise position feedback. The hardened aluminum construction provides excellent wear resistance in high-cycle applications. Includes adjustable cushioning screws for smooth end-of-stroke deceleration.
- Automated production line workpiece positioning
- Robotic arm end-effector clamping systems
- Packaging machine product height detection stations
- Press-fit equipment with position verification
- Conveyor system emergency stop mechanisms
Installation guidelines:
Mount on rigid flat surface using M6 mounting bolts (torque 7-9 N·m).
Maintain 0.5-1mm clearance between stopping block and cylinder rod end.
Lubricate with ISO VG32 hydraulic oil before initial operation.
- Magnetic sensor kit (D-A93 series)
- Heat-resistant seals (up to 120℃)
- Stainless steel rod version (for corrosive environments)
- Rod end accessories (clevis, flange, or ball joints)
| Property | Property Value |
|---|---|
| sku | TDH63X30K |
| Port Size | PT1/4 |
| Proximity Sensor Thread Type | M8×1.0 |
| Magnet | Non-magnetic |
| Bore Diameter | 63mm |
| Self-locking Function | Non Self-locking |
| Stroke | 30mm |
