Airtac TDH Stop Cylinder TDH80X40K
2. Reinforced piston rod design significantly enhances lateral impact resistance capability;
3. Heavy-duty TDH series features integrated oil cushioning or adjustable hydraulic shock absorbers to reliably absorb kinetic energy during impact;
4. Lever-type roller mechanism incorporates a self-locking device that prevents arm rebound and unintended push-back on blocked objects;
5. Multiple configurations and standardized specifications available for customized application requirements.
Category: Stop Cylinders , Brand: AIRTAC , Series: TDH
AirTAC TDH Series Stopper Cylinder TDH80X40K Technical Details
- Model: TDH80X40K
- Bore size: 80mm
- Stroke: 40mm
- Operation type: Double-acting
- Working pressure: 0.05-0.9 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting types: MA/MS/MP/MF (standardized mounting brackets)
- Ambient temperature: -20℃ to 80℃
- Piston material: Aluminum alloy with hard anodization
- Rod material: Stainless steel SUS304
- Seal material: NBR (Nitrile rubber)
- Port size: G1/2 (BSPP thread)
- Protection class: IP54 (standard)
- Weight: 3.2kg ±5% (without accessories)
- Dimensions (L×W×H):
- Basic length: 250mm (minimum retracted position)
- Full stroke length: 290mm
- Body width: 80mm (square housing design)
- Mounting base height: 40mm
Heavy-duty stopper cylinder engineered for precision positioning and impact absorption in automated systems. Features dual shock-absorbing chambers with 5-stage adjustable cushioning, making it ideal for high-cycle operations. The square body design enhances structural rigidity and heat dissipation. Requires ISO 8573-1:2010 [4:4:3] class compressed air.
- Automotive assembly line pallet stoppers
- Robotic welding fixture positioning
- Package dimension verification systems
- Die-casting machine ejection control
- Lithium battery stacking equipment
Maintenance tip:
Lubricate with ISO VG32 pneumatic oil through built-in lubricator ports every 50,000 cycles.
Avoid lateral forces exceeding 200N on the stopper plate during operation.
| Property | Property Value |
|---|---|
| sku | TDH80X40K |
| Port Size | PT1/4 |
| Proximity Sensor Thread Type | M8×1.0 |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Self-locking Function | Non Self-locking |
| Stroke | <40mm> |
