Airtac TDH Stop Cylinder TDH80X40SK
2. Reinforced piston rod design significantly enhances lateral impact resistance capability;
3. Heavy-duty TDH series features integrated oil cushioning or adjustable hydraulic shock absorbers to reliably absorb kinetic energy during impact;
4. Lever-type roller mechanism incorporates a self-locking device that prevents arm rebound and unintended push-back on blocked objects;
5. Multiple configurations and standardized specifications available for customized application requirements.
Category: Stop Cylinders , Brand: AIRTAC , Series: TDH
AirTAC TDH Series Stopper Cylinder TDH80X40SK Technical Details
- Model: TDH80X40SK
- Type: Compact double-acting stopping cylinder
- Bore size: 80mm
- Stroke: 40mm (±20mm adjustable)
- Operating pressure: 0.1–0.9 MPa
- Temperature range: -10℃ to 70℃
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: G1/8 (ISO standard)
- Rod material: Hard chrome-plated steel
- Tube material: Aluminum alloy with hard anodizing
- Seal type: NBR + PU hybrid seals
- Protection class: IP54 (standard)
- Weight: 5.2kg (without accessories)
- Dimensions: 260mm(L) × 80mm(W) × 80mm(H)
- Max stopping force: 1,200N @0.6MPa
- Repeat positioning accuracy: ±0.5mm
Heavy-duty mechanical stopper with integrated shock absorption, featuring dual-position detection slots for magnetic sensor mounting (SM/SD series compatible). The T-shaped mounting base allows both horizontal and vertical installations. Optimized for high-cycle applications with built-in wear compensation mechanism.
- Automated conveyor line product positioning
- Robotic welding station part clamping
- CNC machine tool safety interlocks
- Packaging equipment sequential stopping
- Battery production line pallet alignment
Installation guidelines:
Maintain 0.5-1mm gap between stopper arm and target surface during setup.
Lubricate guide shafts monthly with ISO VG32 hydraulic oil. Avoid side-load
forces exceeding 15% of axial load capacity.
| Property | Property Value |
|---|---|
| sku | TDH80X40SK |
| Port Size | PT1/4 |
| Proximity Sensor Thread Type | M8×1.0 |
| Magnet | S-Magnetic |
| Bore Diameter | 80 mm |
| Self-locking Function | Non Self-locking |
| Stroke | <40mm> |
