Airtac TTG Stopper Cylinder TTG32X20SC
2. Reinforced piston rod design enhances lateral load resistance capability;
3. Adjustable mounting height with multiple rod end configurations. Models equipped with oil cushioning devices deliver superior buffering performance;
4. Lever-type roller mechanism incorporates a self-locking feature to prevent arm rebound and unintended object pushback;
5. Multiple series and specifications available for customized solutions.
Category: Stopper Cylinder | Brand: AIRTAC | Series: TTG
AirTAC TTG Series Blocking Cylinder TTG32X20SC Technical Details
- Model: TTG32X20SC (Standard Configuration)
- Type: Double-acting compact blocking cylinder
- Bore size: Ø32mm (±0.1mm tolerance)
- Stroke: 20mm (Adjustable ±2mm via stopper)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -10℃ to 80℃ (NBR seals)
- Cushioning: Adjustable rubber buffer (both ends)
- Port size: M5x0.8 (Standard) / G1/8 optional
- Mounting: 4x M5 threaded holes (base mounting)
- Rod material: Chrome-plated steel (3-5μm coating)
- Body material: Anodized aluminum alloy (6063-T5)
- Protection rating: IP54 (standard) / IP67 with optional wipers
- Weight: 1.23kg (including all accessories)
- Dimensions: 148mm(L) × 42mm(W) × 42mm(H) (Fully retracted)
High-precision mechanical stop cylinder with integrated position locking, featuring dual-stage sealing for contamination resistance. The TTG32X20SC's through-rod design enables bi-directional force application (Max thrust: 245N @0.6MPa). Requires 40μm filtered lubricated air (ISO 8573-1 class 4).
- Conveyor line product positioning systems
- Palletizing robot end-of-arm tooling
- CNC machine workpiece clamping stations
- Automotive assembly line safety interlocks
- Pharmaceutical blister packaging alignment
Installation protocol:
Mount on vibration-damped surfaces using M5 class 8.8 bolts. Perform monthly
lubrication (ISO VG32 pneumatic oil) and avoid side-load exceeding 15N.
Allow 25mm front clearance for stroke adjustment.
| Property | Property Value |
|---|---|
| sku | TTG32X20SC |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <20mm> |
| Blocking Method | Round Type |
