Airtac TTG Stopper Cylinder TTG32X20SK
2. Reinforced piston rod design enhances lateral load resistance capability;
3. Adjustable mounting height with multiple rod end configurations. Models equipped with oil cushioning devices deliver superior buffering performance;
4. Lever-type roller mechanism incorporates a self-locking feature to prevent arm rebound and unintended object pushback;
5. Multiple series and specifications available for customized solutions.
Category: Stopper Cylinder | Brand: AIRTAC | Series: TTG
AirTAC TTG Series Stopper Cylinder TTG32X20SK Technical Details
- Model: TTG32X20SK
- Type: Double-acting single piston rod stopper cylinder
- Bore size: Ø32mm (±0.1mm tolerance)
- Stroke: 20mm (adjustable via stopper mechanism)
- Operating pressure: 0.1-0.8 MPa
- Port size: PT1/4 (G1/4 optional)
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting: Standard base mounting (ISO 15552 compatible)
- Piston material: Aluminum alloy with hard anodizing
- Rod material: SUS304 stainless steel (chrome-plated option available)
- Seals: NBR standard (FKM/Viton optional)
- Temperature range: -20℃ to 80℃ (dry air required below 0℃)
- Weight: 1.8kg ±3% (without accessories)
- Dimensions: 135mm(L) × 85mm(W) × 85mm(H)
- Protection rating: IP54 (dust protected & water spray resistant)
- Repeat accuracy: ±0.5mm (with proper guide mechanism)
High-precision stopper cylinder featuring integrated mechanical locking mechanism for position retention under pressure loss. The TTG32X20SK combines position sensing grooves (M5 mounting) with dual shock absorption chambers, making it ideal for precision stopping applications requiring both force control and positional accuracy.
- Automotive assembly line part positioning
- PCB conveyor emergency stop systems
- Packaging machine product counting stations
- Robotic welding fixture locking
- Pharmaceutical vial capping force control
Installation notes:
- Align stopper surface perpendicular to workpiece path (±1° max deviation)
- Maintain 0.5-1mm gap between stopper face and target surface
- Use M3x0.5 mounting screws with 5.5Nm torque limit
| Property | Property Value |
|---|---|
| sku | TTG32X20SK |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <20mm> |
| Blocking Method | Lever Roller Type |
