Airtac TTQ Stopper Cylinder TTQ20X10B
1. Complies with JIS standards;
2. Reinforced piston rod design significantly enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations - Optional hydraulic shock absorber delivers superior cushioning performance;
4. Lever roller mechanism integrates self-locking device that prevents arm rebound and ensures secure obstruction of target objects;
5. Comprehensive series/specification options for flexible integration into diverse applications.
Category: Stop Cylinders , Brand: AirTAC , Series: TTQ
AirTAC TTQ Series Stopper Cylinder TTQ20X10B Technical Details
- Model: TTQ20X10B
- Type: Double-acting stopper cylinder with mechanical lock
- Bore size: 20mm
- Stroke: 10mm ±0.5mm
- Operating pressure: 0.05–0.8 MPa
- Temperature range: -10℃ to 80℃
- Cushioning: Adjustable pneumatic cushion
- Mounting style: Side/Flange mounting (M4 screw holes)
- Port size: M5×0.8 (Rc1/8 adapter optional)
- Body material: Anodized aluminum alloy
- Piston rod material: Stainless steel (SUS304)
- Repeat accuracy: ±0.1mm
- Max speed: 500mm/s
- Weight: 0.68kg (including fittings)
- Dimensions: 146mm(L) × 40mm(W) × 40mm(H)
Precision stopper cylinder designed for positioning and blocking applications in automated systems. Features integrated shock absorption with 3-stage adjustable cushioning and dual magnetic sensor slots (NPN/PNP compatible). Corrosion-resistant construction with IP54 protection rating ensures reliable operation in dusty environments.
- Workpiece positioning in CNC machine tool changers
- Conveyor line stopper mechanisms
- Pallet locking in automated warehouses
- Precision alignment in PCB assembly equipment
- Safety interlocks in robotic workcells
Installation tip:
Lubricate with ISO VG32 hydraulic oil before initial operation.
Maintain 0.3mm minimum clearance between stopper rod and target surface.
Use anti-vibration washers when mounting to aluminum frames.
| Property | Property Value |
|---|---|
| sku | TTQ20X10B |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <10mm> |
| Blocking Method | Flat Cylinder |
