Airtac TTQ Stopper Cylinder TTQ20X10C
1. Complies with JIS standards;
2. Reinforced piston rod design significantly enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations - Optional hydraulic shock absorber delivers superior cushioning performance;
4. Lever roller mechanism integrates self-locking device that prevents arm rebound and ensures secure obstruction of target objects;
5. Comprehensive series/specification options for flexible integration into diverse applications.
Category: Stop Cylinders , Brand: AirTAC , Series: TTQ
AirTAC TTQ Series Stopper Cylinder TTQ20X10C Specifications
- Model: TTQ20X10C
- Type: Double-acting single rod stopper cylinder
- Bore size: 20mm
- Stroke: 10mm
- Operating pressure: 0.1–0.8 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable elastic cushion (both ends)
- Material: Aluminum alloy body (hard anodized), CRMo steel rod
- Seal material: NBR rubber with wear-resistant ring
- Mounting type: Standard flange mounting (MF series compatible)
- Port size: M5x0.8 pneumatic ports
- Weight: 0.52kg ±2%
- Dimensions: 80mm(L) × 50mm(W) × 50mm(H)
- Protection rating: IP40 (dust resistant)
- Max piston speed: 500mm/s
- Repeat positioning accuracy: ±0.1mm
Precision stopper cylinder with integrated mechanical locking mechanism, designed for workpiece positioning and flow control in automated assembly lines. Features dual anti-rotation guide rods for enhanced lateral load capacity (max 10N·m). Optimized cushion design reduces impact noise to ≤70dB(A).
- Conveyor belt stopper systems in packaging machinery
- PCB board positioning in SMT production lines
- Fixture locking in automotive welding stations
- Carton alignment in logistics sorting systems
- Precision part clamping in CNC machining centers
Installation note:
Requires 0.5-1mm lateral clearance during mounting. Lubricate with ISO VG32 hydraulic oil
before initial use. Avoid side-load exceeding 30% of maximum thrust capacity.
- Relubrication interval: Every 500,000 cycles
- Seal replacement: Every 3 million cycles
- Rod inspection: Monthly visual check for scoring
| Property | Property Value |
|---|---|
| sku | TTQ20X10C |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <10mm> |
| Blocking Method | Round Type |
