Airtac TTQ Stopper Cylinder TTQ20X10R
$46.75
Regular price
$54.25
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TTQ20X10R
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
TTQ Stop Cylinder
1. Complies with JIS standards;
2. Reinforced piston rod design significantly enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations - Optional hydraulic shock absorber delivers superior cushioning performance;
4. Lever roller mechanism integrates self-locking device that prevents arm rebound and ensures secure obstruction of target objects;
5. Comprehensive series/specification options for flexible integration into diverse applications.
Category: Stop Cylinders , Brand: AirTAC , Series: TTQ
Installation tip:
Align stopper surface perpendicular to workpiece flow direction.
Use 0.5mm adjustment shims for Z-axis height calibration.
Lubricate guide shafts monthly with ISO VG32 hydraulic oil.
1. Complies with JIS standards;
2. Reinforced piston rod design significantly enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations - Optional hydraulic shock absorber delivers superior cushioning performance;
4. Lever roller mechanism integrates self-locking device that prevents arm rebound and ensures secure obstruction of target objects;
5. Comprehensive series/specification options for flexible integration into diverse applications.
Category: Stop Cylinders , Brand: AirTAC , Series: TTQ
AirTAC TTQ Series Stopper Cylinder TTQ20X10R Specifications
- Model: TTQ20X10R
- Type: Compact double-acting stopper cylinder
- Bore size: Ø20mm
- Stroke: 10mm
- Operating pressure: 0.1–0.8 MPa
- Operating temperature: -20℃ to 80℃
- Cushion type: Adjustable rubber buffer
- Mounting style: Side mounting holes + front flange
- Port size: M5x0.8 (standard) / NPT1/8 (optional)
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel SUS304
- Seal material: NBR (nitrile rubber)
- Repeat accuracy: ±0.1mm
- Weight: 0.48kg
- Dimensions: 98mm(L) × 24mm(W) × 42mm(H)
- Protection rating: IP40
- Max thrust: 58N @0.5MPa
High-precision mechanical stopper with integrated cylinder for precise workpiece positioning. Features anti-rotation mechanism and shock-absorbing structure, ideal for high-cycle automated processes. Requires clean compressed air (ISO 8573-1:2010 Class 3.4.2).
Typical Applications:
- PCB conveyor positioning systems
- Automotive part assembly fixtures
- Robotic pick-and-place end effectors
- Pharmaceutical blister packaging machines
- Semiconductor wafer handling equipment
Installation tip:
Align stopper surface perpendicular to workpiece flow direction.
Use 0.5mm adjustment shims for Z-axis height calibration.
Lubricate guide shafts monthly with ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | TTQ20X10R |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <10mm> |
| Blocking Method | Roller Type |
