Airtac TTQ Stopper Cylinder TTQ20X15B
1. Complies with JIS standards;
2. Reinforced piston rod design significantly enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations - Optional hydraulic shock absorber delivers superior cushioning performance;
4. Lever roller mechanism integrates self-locking device that prevents arm rebound and ensures secure obstruction of target objects;
5. Comprehensive series/specification options for flexible integration into diverse applications.
Category: Stop Cylinders , Brand: AirTAC , Series: TTQ
AirTAC TTQ Series Stopper Cylinder TTQ20X15B Technical Details
- Model: TTQ20X15B
- Bore size: Ø20mm
- Stroke: 15mm
- Operation type: Double-acting with spring return
- Working pressure: 0.05-0.8 MPa
- Port thread: M5×0.8 (standard) / NPT1/8 optional
- Cushioning type: Adjustable rubber buffer
- Piston speed: 50-750 mm/s
- Ambient temperature: -20℃ to 80℃
- Material:
- Cylinder tube: Aluminum alloy (hard anodized)
- Piston rod: Stainless steel (SUS304)
- Seals: NBR + PU combination
- Mounting: Standard ISO 6432 with front flange
- Weight: 0.6kg ±2%
- Dimensions:
- Extended length: 89mm
- Retracted length: 74mm
- Body width: 40mm
- Mounting hole spacing: 25mm (center-to-center)
- Rod end thread: M6×1.0
Precision stopper cylinder with integrated shock absorption, featuring a dual-seal design for contamination resistance in ISO 8573-1 class 4 environments. The chrome-plated guide sleeve ensures smooth linear motion, while the magnetic piston enables position feedback when paired with sensors (optional). Requires 5μm filtered air with ISO VG32 lubricant.
- Position verification in robotic pick-and-place systems
- Workpiece alignment gates in CNC loading stations
- Safety interlocks in automated assembly lines
- Clamping mechanisms for PCB test fixtures
- Partition control in pharmaceutical blister packaging
Operational guidance:
Maintain ≤0.5mm perpendicularity tolerance during installation.
For vertical mounting, use anti-rotation brackets (accessory code: ARB-20).
Lubricate every 500,000 cycles under normal load conditions.
| Property | Property Value |
|---|---|
| sku | TTQ20X15B |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <15mm> |
| Blocking Method | Flat Cylinder |
