Airtac TTQ Stopper Cylinder TTQ20X15SC
1. Complies with JIS standards;
2. Reinforced piston rod design significantly enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations - Optional hydraulic shock absorber delivers superior cushioning performance;
4. Lever roller mechanism integrates self-locking device that prevents arm rebound and ensures secure obstruction of target objects;
5. Comprehensive series/specification options for flexible integration into diverse applications.
Category: Stop Cylinders , Brand: AirTAC , Series: TTQ
AirTAC TTQ20X15SC Blocking Cylinder Specifications
- Model: TTQ20X15SC
- Type: Single-acting spring return blocking cylinder
- Bore size: Ø20mm
- Stroke: 15mm (±1mm adjustability)
- Operating pressure: 0.1–0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer
- Mounting style: Side/Flange mount (M4 threaded holes)
- Port size: M5x0.8 (standard) / Optional NPT1/8
- Body material: Anodized aluminum alloy
- Rod material: Stainless steel (SUS304)
- Seal material: NBR (Nitrile rubber)
- Weight: 0.62kg ±2%
- Dimensions: 90mm(L) × 40mm(W) × 40mm(H)
- Repeat accuracy: ±0.2mm
- Max lateral load: 15N
- ISO certification: 6431/15552 compliant
Compact linear blocking cylinder with precision-machined guide rails, designed for position locking and workpiece interception in confined spaces. Features wear-resistant chromium-plated rod and dual anti-rotation pins for stable vertical/horizontal operation. Includes built-in magnet for position sensing compatibility.
- Conveyor line workpiece stoppers
- Robotic arm end-of-stroke positioning
- PCB handling machine buffer stations
- Automated sorting system gate control
- Medical device assembly positioning
Installation note:
Lubricate rod with ISO VG32 hydraulic oil before initial use.
Maintain 0.5mm minimum clearance between stopper and workpiece
during alignment. Avoid side impact forces exceeding 10N.
| Property | Property Value |
|---|---|
| sku | TTQ20X15SC |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <15mm> |
| Blocking Method | Round Type |
