Airtac TTQ Stopper Cylinder TTQ25X10R
$53.73
Regular price
$61.23
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TTQ25X10R
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
TTQ Stop Cylinder
1. Complies with JIS standards;
2. Reinforced piston rod design significantly enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations - Optional hydraulic shock absorber delivers superior cushioning performance;
4. Lever roller mechanism integrates self-locking device that prevents arm rebound and ensures secure obstruction of target objects;
5. Comprehensive series/specification options for flexible integration into diverse applications.
Category: Stop Cylinders , Brand: AirTAC , Series: TTQ
Installation notes:
Maintain 0.5-1mm clearance between stopper rod and target surface during setup.
For vertical installations, use locking nut (M6) to prevent rotation. Lubricate sliding
surfaces with ISO VG32 hydraulic oil every 500km operation.
1. Complies with JIS standards;
2. Reinforced piston rod design significantly enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations - Optional hydraulic shock absorber delivers superior cushioning performance;
4. Lever roller mechanism integrates self-locking device that prevents arm rebound and ensures secure obstruction of target objects;
5. Comprehensive series/specification options for flexible integration into diverse applications.
Category: Stop Cylinders , Brand: AirTAC , Series: TTQ
AirTAC TTQ Series Stopper Cylinder TTQ25X10R Specifications
- Model: TTQ25X10R
- Bore size: 25mm
- Stroke: 10mm
- Operation type: Double-acting
- Working pressure: 0.05-0.8 MPa
- Cushioning: Adjustable cushioning (both ends)
- Actuation method: Manual override available (rotary knob)
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8
- Rod thread: M6x1.0
- Body material: Aluminum alloy (anodized) + engineering plastic
- Seal material: NBR
- Weight: 0.65kg ±3%
- Dimensions: 110mm(L) × 25mm(W) × 25mm(H) (standard position)
- Repeat accuracy: ±0.5mm
- Protection rating: IP54 (standard)
- Lubrication: Pre-lubricated (DOP oil)
Compact mechanical stopper cylinder with precise position control, featuring dual adjustable rubber cushions for shock absorption. The T-slot mounting design enables multi-angle installation. Integrated dust wiper prevents particle ingress in dirty environments.
Typical Applications:
- Conveyor line positioning systems
- Robotic end-effector tool changers
- Carton box height limitation in packaging
- PCB board stopper in SMT equipment
- Workpiece alignment in CNC loaders
Installation notes:
Maintain 0.5-1mm clearance between stopper rod and target surface during setup.
For vertical installations, use locking nut (M6) to prevent rotation. Lubricate sliding
surfaces with ISO VG32 hydraulic oil every 500km operation.
| Property | Property Value |
|---|---|
| sku | TTQ25X10R |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <25 mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <10mm> |
| Blocking Method | Roller Type |
