Airtac TTQ Stopper Cylinder TTQ25X15R
$55.12
Regular price
$62.62
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TTQ25X15R
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
TTQ Stop Cylinder
1. Complies with JIS standards;
2. Reinforced piston rod design significantly enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations - Optional hydraulic shock absorber delivers superior cushioning performance;
4. Lever roller mechanism integrates self-locking device that prevents arm rebound and ensures secure obstruction of target objects;
5. Comprehensive series/specification options for flexible integration into diverse applications.
Category: Stop Cylinders , Brand: AirTAC , Series: TTQ
Installation note:
Ensure 0.5-1mm clearance between stopper face and target surface during setup.
Use C-shaped mounting brackets (sold separately) for vertical applications.
Requires 5μm filtered air with 1-3 drops of ISO VG32 oil per m³.
1. Complies with JIS standards;
2. Reinforced piston rod design significantly enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations - Optional hydraulic shock absorber delivers superior cushioning performance;
4. Lever roller mechanism integrates self-locking device that prevents arm rebound and ensures secure obstruction of target objects;
5. Comprehensive series/specification options for flexible integration into diverse applications.
Category: Stop Cylinders , Brand: AirTAC , Series: TTQ
AirTAC TTQ25X15R Stopper Cylinder Specifications
- Model: TTQ25X15R
- Type: Rodless compact stopper cylinder
- Bore size: Ø25mm
- Stroke: 15mm ±0.5mm
- Operating pressure: 0.1–0.8 MPa
- Buffer type: Rubber cushion (adjustable end position)
- Ambient temperature: -20℃ to 80℃
- Material: Aluminum alloy body, chrome-plated piston rod
- Seal material: NBR (Nitrile rubber)
- Port size: M5x0.8 (dual ports)
- Mounting type: Horizontal slot + 2xM5 threaded holes
- Repeat accuracy: ±0.2mm
- Weight: 480g ±3%
- Dimensions: 98mm(L) × 42mm(W) × 36mm(H)
- Protection rating: IP54 (standard)
- Lubrication: Pre-lubricated (DOP mist compatible)
High-precision mechanical stopper with integrated air cylinder, designed for position locking in confined spaces. Features dual air ports for bidirectional control and anti-rotation guide mechanism. The chrome-plated rod resists scoring in high-cycle applications.
Typical Applications:
- PCB conveyor positioning systems
- Robotic arm end effector alignment
- Pharmaceutical blister pack indexing
- Automotive part fixture clamping
- Bottle capping machine height adjustment
Installation note:
Ensure 0.5-1mm clearance between stopper face and target surface during setup.
Use C-shaped mounting brackets (sold separately) for vertical applications.
Requires 5μm filtered air with 1-3 drops of ISO VG32 oil per m³.
| Property | Property Value |
|---|---|
| sku | TTQ25X15R |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <25 mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <15mm> |
| Blocking Method | Roller Type |
