Airtac TTQ Stopper Cylinder TTQ25X15SR
$58.12
Regular price
$65.62
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TTQ25X15SR
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
TTQ Stop Cylinder
1. Complies with JIS standards;
2. Reinforced piston rod design significantly enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations - Optional hydraulic shock absorber delivers superior cushioning performance;
4. Lever roller mechanism integrates self-locking device that prevents arm rebound and ensures secure obstruction of target objects;
5. Comprehensive series/specification options for flexible integration into diverse applications.
Category: Stop Cylinders , Brand: AirTAC , Series: TTQ
Installation note:
Lubricate with ISO VG32 turbine oil before initial operation.
Avoid lateral loading exceeding 15N. For vertical mounting,
use mechanical locknut (accessory code: LK-25SR).
1. Complies with JIS standards;
2. Reinforced piston rod design significantly enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations - Optional hydraulic shock absorber delivers superior cushioning performance;
4. Lever roller mechanism integrates self-locking device that prevents arm rebound and ensures secure obstruction of target objects;
5. Comprehensive series/specification options for flexible integration into diverse applications.
Category: Stop Cylinders , Brand: AirTAC , Series: TTQ
AirTAC TTQ25X15SR Stopper Cylinder Specifications
- Model: TTQ25X15SR
- Type: Double-acting stopper cylinder with spring return
- Bore size: 25mm
- Stroke: 15mm
- Operating pressure: 0.05–0.9 MPa
- Operating temperature: -10℃ to 70℃
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Cushion type: Adjustable air cushion
- Piston rod material: Stainless steel (SUS304)
- Tube material: Aluminum alloy (hard anodized)
- Seal material: NBR + PU combination
- Weight: 0.42kg ±2%
- Dimensions: 85mm(L) × 32mm(W) × 32mm(H)
- Mounting style: Standard flange base with 4xM5 threaded holes
- Repeat positioning accuracy: ±0.1mm
- Protection rating: IP54 (standard)
Precision stopper cylinder with integrated shock absorption, designed for high-speed positioning and workpiece stopping in automated systems. Features wear-resistant dual-material seals and anti-rotation piston rod. Requires 5μm filtered dry air (dew point -20℃ below ambient).
Typical Applications:
- Conveyor line product positioning systems
- Robotic arm end-effector alignment
- PCB board clamping mechanisms
- Pharmaceutical blister packaging machines
- Automotive parts assembly stations
Installation note:
Lubricate with ISO VG32 turbine oil before initial operation.
Avoid lateral loading exceeding 15N. For vertical mounting,
use mechanical locknut (accessory code: LK-25SR).
| Property | Property Value |
|---|---|
| sku | TTQ25X15SR |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <25 mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <15mm> |
| Blocking Method | Roller Type |
