Airtac TWG Stop Cylinder TWG32X10KF
$92.35
Regular price
$99.85
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TWG32X10KF
Product type:
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Complies with JIS (Japanese Industrial Standards) specifications;
2、Reinforced piston rod design significantly enhances cylinder's resistance to lateral bending moments;
3、Adjustable mounting height with multiple rod end configurations, optional oil-cushioned shock absorber ensures superior damping performance;
4、Lever-type roller mechanism integrated with self-locking device prevents arm rebound-induced pushback on blocked objects;
5、Multiple series and specifications available to meet diverse industrial automation requirements.
Category: Blocking Cylinder | Brand: AIRTAC | Series: TWG
Installation guidelines:
Maintain 0.5-1mm clearance between stopper face and target surface during setup.
Lubricate with ISO VG32 hydraulic oil. Maximum side load: 15N.
For vertical mounting, use auxiliary support brackets (AS-32 accessory recommended).
2、Reinforced piston rod design significantly enhances cylinder's resistance to lateral bending moments;
3、Adjustable mounting height with multiple rod end configurations, optional oil-cushioned shock absorber ensures superior damping performance;
4、Lever-type roller mechanism integrated with self-locking device prevents arm rebound-induced pushback on blocked objects;
5、Multiple series and specifications available to meet diverse industrial automation requirements.
Category: Blocking Cylinder | Brand: AIRTAC | Series: TWG
AirTAC TWG Series Stopper Cylinder TWG32X10KF Technical Details
- Model: TWG32X10KF
- Type: Compact mechanical stopper cylinder
- Bore size: 32mm
- Stroke: 10mm
- Operation: Double-acting
- Operating pressure: 0.05–0.8 MPa
- Cushioning type: Adjustable pneumatic cushion (both ends)
- Mounting style: Side or flange mounting (MF1/MF2 options)
- Port size: G1/8 (NPT1/8 optional)
- Temperature range: -10℃ to 80℃
- Material: Aluminum alloy body, stainless steel rod
- Seal material: NBR (nitrile rubber)
- Protection rating: IP54
- Weight: 1.8kg ±3%
- Dimensions: 200mm(L) × 32mm(W) × 32mm(H) (standard stroke position)
Precision stopper cylinder with integrated shock absorption, designed for high-cycle positioning tasks. Features wear-resistant chromium-plated rod and anti-rotation mechanism for stable blocking force. The KF variant includes enhanced dust wipers for contaminated environments.
Industrial Applications:
- Workpiece positioning in CNC pallet systems
- Carton alignment in packaging machinery
- Safety interlocks in automotive assembly lines
- Precision stopping in semiconductor handling robots
- Gate control in conveyor sorting systems
Installation guidelines:
Maintain 0.5-1mm clearance between stopper face and target surface during setup.
Lubricate with ISO VG32 hydraulic oil. Maximum side load: 15N.
For vertical mounting, use auxiliary support brackets (AS-32 accessory recommended).
| Property | Property Value |
|---|---|
| sku | TWG32X10KF |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Self-locking Function | Self-locking |
| Stroke | <10mm> |
| Blocking Method | Lever Roller Type |
