Airtac TWG Stop Cylinder TWG32X15SB
$52.07
Regular price
$59.57
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TWG32X15SB
Product type:
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Complies with JIS (Japanese Industrial Standards) specifications;
2、Reinforced piston rod design significantly enhances cylinder's resistance to lateral bending moments;
3、Adjustable mounting height with multiple rod end configurations, optional oil-cushioned shock absorber ensures superior damping performance;
4、Lever-type roller mechanism integrated with self-locking device prevents arm rebound-induced pushback on blocked objects;
5、Multiple series and specifications available to meet diverse industrial automation requirements.
Category: Blocking Cylinder | Brand: AIRTAC | Series: TWG
Installation protocol:
Mount on rigid flat surfaces with M5x0.8 screws (torque 3.5Nm).
Lubricate with ISO VG32 pneumatic oil before initial operation.
Maintain 0.3mm minimum clearance between stopper and contact surface.
2、Reinforced piston rod design significantly enhances cylinder's resistance to lateral bending moments;
3、Adjustable mounting height with multiple rod end configurations, optional oil-cushioned shock absorber ensures superior damping performance;
4、Lever-type roller mechanism integrated with self-locking device prevents arm rebound-induced pushback on blocked objects;
5、Multiple series and specifications available to meet diverse industrial automation requirements.
Category: Blocking Cylinder | Brand: AIRTAC | Series: TWG
AirTAC TWG Series Stopper Cylinder TWG32X15SB Technical Details
- Model: TWG32X15SB
- Type: Double-acting mechanical stopper cylinder
- Bore size: Ø32mm
- Stroke: 15mm ±0.5mm
- Operating pressure: 0.1–0.8 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting style: Square flange (ISO 15552 standard)
- Temperature range: -20℃ to 80℃
- Body material: Aluminum alloy (anodized finish)
- Rod material: Chrome-plated steel
- Seal material: NBR (nitrile rubber)
- Weight: 0.82kg ±3%
- Dimensions: 150mm(L) × 52mm(W) × 52mm(H)
- Port size: M5x0.8 (standard) or NPT1/8 optional
- Repeat accuracy: ±0.2mm
- Max thrust: 201N @ 0.6MPa
Precision stopper cylinder with integrated mechanical locking mechanism, featuring wear-resistant guide bushings and dual shock absorption. The TWG32X15SB's anti-rotation design maintains positional accuracy during high-cycle operations. Requires ISO 8573-1:2010 Class 3 compressed air.
Industrial Applications:
- Conveyor line positioning systems
- Robotic welding fixture locking
- CNC machine tool pallet changers
- Automotive assembly line part retention
- Packaging machine product alignment
Installation protocol:
Mount on rigid flat surfaces with M5x0.8 screws (torque 3.5Nm).
Lubricate with ISO VG32 pneumatic oil before initial operation.
Maintain 0.3mm minimum clearance between stopper and contact surface.
| Property | Property Value |
|---|---|
| sku | TWG32X15SB |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <15mm> |
| Blocking Method | Flat Cylinder |
