Airtac TWH Stop Cylinder TWH20X15LF
2. Reinforced piston rod design significantly enhances impact resistance and operational stability;
3. Heavy-duty construction integrates oil buffer systems or adjustable hydraulic shock absorbers for efficient energy absorption during impact;
4. Lever-type roller mechanism with integrated self-locking device prevents arm rebound and ensures secure object retention;
5. Multiple series and specifications available to accommodate diverse application requirements.
Category: Stopper Cylinders | Brand: AirTAC | Series: TWH
AirTAC TWH Series Stopper Cylinder TWH20X15LF Technical Details
- Model: TWH20X15LF
- Bore size: Ø20mm
- Stroke: 15mm
- Operation: Double-acting with spring return
- Operating pressure: 0.15–0.8 MPa
- Cushioning: Adjustable pneumatic cushion
- Mounting: Standard flange (MF1) with 4xM5 threaded holes
- Port size: 1/8" NPT (G1/8 optional)
- Piston rod material: Stainless steel (SUS304)
- Cylinder tube: Hard anodized aluminum alloy
- Seal material: Nitrile rubber (NBR)
- Temperature range: -20℃ to 80℃
- Weight: 0.52kg ±3%
- Dimensions: 110mm(L) × 40mm(W) × 40mm(H) (at fully retracted position)
- Stroke tolerance: +1.5mm
- Max lateral load: 15N at rod end
- Protection rating: IP54 (standard seals)
Precision stopper cylinder with integrated shock absorption, designed for repetitive positioning tasks requiring millimeter-level accuracy. Features wear-resistant chromium-plated guide rod and anti-rotation mechanism for stable vertical operation. Requires 5μm filtered lubricated air (ISO 8573-1 class 3).
- PCB board positioning in SMT assembly lines
- Workpiece alignment in CNC machine tool changers
- Package gate control in sorting conveyor systems
- Precision stopper in automotive part fixtures
- Carton height adjustment in packaging machinery
Installation guidelines:
Maintain 0.05mm maximum misalignment during mounting. Lubricate with ISO VG32 hydraulic oil
during initial setup. Perform maintenance every 500,000 cycles or 6 months (whichever comes first).
Avoid side load exceeding 10% of maximum thrust capacity.
| Property | Property Value |
|---|---|
| sku | TWH20X15LF |
| Port Size | M5×0.8 |
| Proximity Sensor Thread Type | M5×0.5 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Self-locking Function | Self-locking |
| Stroke | <15mm> |
