Airtac TWH Stop Cylinder TWH40X30KF
2. Reinforced piston rod design significantly enhances impact resistance and operational stability;
3. Heavy-duty construction integrates oil buffer systems or adjustable hydraulic shock absorbers for efficient energy absorption during impact;
4. Lever-type roller mechanism with integrated self-locking device prevents arm rebound and ensures secure object retention;
5. Multiple series and specifications available to accommodate diverse application requirements.
Category: Stopper Cylinders | Brand: AirTAC | Series: TWH
AirTAC TWH Series Blocking Cylinder TWH40X30KF Technical Details
- Model: TWH40X30KF
- Type: Double-acting rodless blocking cylinder
- Bore size: 40mm (ISO 6432 standard)
- Stroke: 30mm (±1mm tolerance)
- Operating pressure: 0.05–0.9 MPa
- Ambient temperature: -20℃ to 80℃
- Piston speed: 50–800 mm/s
- Cushioning: Adjustable pneumatic cushion (3-stage)
- Port size: M5x0.8 (standard) / NPT1/8 (optional)
- Mounting type: Front flange with 4xM5 threaded holes
- Material: Aluminum alloy body (AL6063-T5), CRCC steel guide rod
- Seal type: HNBR seals with wear-resistant ring
- Repeat accuracy: ±0.2mm
- Weight: 1.48kg (without accessories)
- Dimensions: 165mm(L) × 40mm(W) × 40mm(H) (full extension)
- Protection class: IP54 (standard) / IP67 (optional with wiper upgrade)
- Magnetic switch compatibility: D-A93 series (non-embedding type)
High-precision linear blocking cylinder featuring anti-rotation mechanism and dual-channel guide structure. The TWH40X30KF incorporates a unique wedge-shaped brake system that achieves 2.5x greater holding force compared to conventional models. Its anodized surface treatment provides enhanced corrosion resistance for humid environments.
- Automated conveyor line stopper mechanisms
- CNC machine tool workpiece positioning
- Robotic arm end-effector locking systems
- Semiconductor wafer handling equipment
- Automotive assembly line pallet retention
Installation guidelines:
Requires perpendicular mounting surface with ≤0.1mm/m flatness.
Lubricate with ISO VG32 hydraulic oil before initial operation.
Maintain 0.3-0.5MPa residual pressure during locking phase.
| Property | Property Value |
|---|---|
| sku | TWH40X30KF |
| Port Size | PT1/8 |
| Proximity Sensor Thread Type | M5×0.5 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Self-locking Function | Self-locking |
| Stroke | 30mm |
