Airtac TWH Stop Cylinder TWH40X30SK
2. Reinforced piston rod design significantly enhances impact resistance and operational stability;
3. Heavy-duty construction integrates oil buffer systems or adjustable hydraulic shock absorbers for efficient energy absorption during impact;
4. Lever-type roller mechanism with integrated self-locking device prevents arm rebound and ensures secure object retention;
5. Multiple series and specifications available to accommodate diverse application requirements.
Category: Stopper Cylinders | Brand: AirTAC | Series: TWH
AirTAC TWH40X30SK Stopper Cylinder Technical Details
- Model: TWH40X30SK
- Type: Compact double-acting stopper cylinder
- Bore size: 40mm
- Stroke: 30mm (±1mm tolerance)
- Operating pressure: 0.1–0.8 MPa
- Piston speed: 50–700 mm/s (lubricated)
- Cushioning: Adjustable pneumatic cushion
- Mounting style: Front flange (MF1) with side tapped holes
- Port size: G1/8 (BSPP thread)
- Piston material: Aluminum alloy hard anodized
- Rod material: Chrome-plated steel (Cr12MoV)
- Seal type: HNBR seals with wear-resistant ring
- Temperature range: -20℃ to 80℃
- Weight: 1.8 kg (without accessories)
- Dimensions: 200mm(L) × 65mm(W) × 65mm(H) (fully retracted)
- Protection class: IP54 (standard wiper design)
- Repeat accuracy: ±0.5mm
High-precision stopper cylinder with integrated shock absorption, engineered for precision part positioning and workpiece blocking in automated systems. Features dual guide rods for enhanced lateral stability and tungsten carbide-treated contact surfaces for extended cycle life. Requires ISO 8573-1:2010 Class 3 compressed air.
- Automotive assembly line part positioning
- CNC machine tool pallet locking
- Packaging conveyor flow control gates
- Robotic welding fixture sequencing
- Electronics PCB buffer stations
Installation guidelines:
Maintain 0.02mm/m alignment tolerance during mounting. Apply Molykote 111 lubricant
to guide rods every 50,000 cycles. Maximum side load capacity: 150N at full extension.
| Property | Property Value |
|---|---|
| sku | TWH40X30SK |
| Port Size | PT1/8 |
| Proximity Sensor Thread Type | M5×0.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <40mm> |
| Self-locking Function | Non Self-locking |
| Stroke | 30mm |
