Airtac TWH Stop Cylinder TWH80X40SK
2. Reinforced piston rod design significantly enhances impact resistance and operational stability;
3. Heavy-duty construction integrates oil buffer systems or adjustable hydraulic shock absorbers for efficient energy absorption during impact;
4. Lever-type roller mechanism with integrated self-locking device prevents arm rebound and ensures secure object retention;
5. Multiple series and specifications available to accommodate diverse application requirements.
Category: Stopper Cylinders | Brand: AirTAC | Series: TWH
AirTAC TWH Series Stopper Cylinder TWH80X40SK Technical Details
- Model: TWH80X40SK
- Type: Double-acting single piston rod stopper cylinder
- Bore size: Ø80mm
- Stroke: 40mm (customizable 20-200mm)
- Operating pressure: 0.05-1.0 MPa
- Piston speed: 50-700mm/s (cushioned)
- Ambient temperature: -10℃ to 60℃
- Mounting type: Standard flange (MF1) with reinforced base
- Rod end: External M30×1.5 thread
- Cushioning: Adjustable rubber buffers at both ends
- Seal material: Heat-resistant NBR with wear ring
- Weight: 3.8kg (excluding accessories)
- Dimensions: 200mm(L) × 100mm(W) × 100mm(H) (extended length)
- Repeat accuracy: ±0.5mm
- Air connection: 2×G1/4 ports (stainless steel thread inserts)
- Position detection: Built-in magnet for magnetic switch (SM/SMC series compatible)
Heavy-duty mechanical stopper cylinder with integrated shock absorption, designed for high-cycle precision positioning in automated production lines. Features chromium-plated piston rod and anodized aluminum barrel for corrosion resistance. Requires 5-40μm filtered lubricated air (ISO 8573-1 class 4).
- Pallet stop mechanisms in conveyor systems
- Workpiece positioning in CNC machine loaders
- Clamping gates in automotive welding fixtures
- Elevator positioning in vertical storage systems
- Safety interlocks in press machinery
Installation guidelines:
Align cylinder axis perpendicular to stopping surface. Apply thread lock
to mounting bolts (recommended torque 58N·m). Maintain 0.5mm minimum gap
between stopper plate and cylinder head during calibration.
| Property | Property Value |
|---|---|
| sku | TWH80X40SK |
| Port Size | PT1/4 |
| Proximity Sensor Thread Type | M8×1.0 |
| Magnet | S-Magnetic |
| Bore Diameter | 80 mm |
| Self-locking Function | Non Self-locking |
| Stroke | <40mm> |
