Airtac TWQ Stopper Cylinder TWQ20X10R
1. Compliant with JIS standards;
2. Reinforced piston rod design effectively enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations. Hydraulic shock absorber option delivers superior cushioning performance;
4. Lever-type roller mechanism incorporates self-locking device to prevent rebound pushback from blocked objects;
5. Comprehensive series and specifications available for diverse application needs.
Category: Stopper Cylinder | Brand: AIRTAC | Series: TWQ
AirTAC TWQ Series Stopper Cylinder TWQ20X10R Technical Specifications
- Model Code: TWQ20X10R
- Bore Size: Ø20mm
- Stroke: 10mm
- Action Type: Double-acting with spring return
- Operating Pressure: 0.05-0.9 MPa
- Maximum Thrust: 63N (at 0.63MPa)
- Piston Speed: 50-750mm/s
- Cushion Type: Adjustable rubber buffer
- Mounting Style: Front flange with 4×M5 threaded holes
- Rod End: M6×1.0 external thread
- Body Material: Aluminum alloy (anodized finish)
- Seal Material: NBR (nitrile rubber)
- Ambient Temp Range: -20℃ to 80℃
- Weight: 0.42kg ±3%
- Dimensions (L×W×H): 105mm × 34mm × 34mm (excluding rod extension)
- ISO Standard: Compliant with ISO 6432
Precision stopper cylinder featuring dual-position locking mechanism for secure workpiece positioning in automated systems. The TWQ20X10R's compact profile and anti-rotation rod design ensure stable operation in space-constrained environments. Includes wear-resistant guide bushings and IP54-rated protection against particulate contamination.
- Conveyor line product positioning gates
- CNC machine tool fixture locking
- Robotic assembly station part alignment
- Packaging machine carton stoppers
- Electronic component press-fit mechanisms
Installation Guidelines:
Maintain 0.5-1mm clearance between stopper rod and target surface during setup.
Lubricate with ISO VG32 hydraulic oil before initial use. Avoid side-load forces exceeding 15N.
| Property | Property Value |
|---|---|
| sku | TWQ20X10R |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <10mm> |
| Blocking Method | Roller Type |
