Airtac TWQ Stopper Cylinder TWQ20X10SB
1. Compliant with JIS standards;
2. Reinforced piston rod design effectively enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations. Hydraulic shock absorber option delivers superior cushioning performance;
4. Lever-type roller mechanism incorporates self-locking device to prevent rebound pushback from blocked objects;
5. Comprehensive series and specifications available for diverse application needs.
Category: Stopper Cylinder | Brand: AIRTAC | Series: TWQ
AirTAC TWQ Series Stopper Cylinder TWQ20X10SB Technical Details
- Model: TWQ20X10SB
- Type: Compact double-acting stopper cylinder
- Bore size: 20mm
- Stroke: 10mm (±1mm tolerance)
- Operating pressure: 0.1–0.8 MPa
- Port size: M5x0.8 (1/8" NPT optional)
- Cushioning: Adjustable pneumatic cushion
- Mounting style: SB-type (front flange with side mounting holes)
- Temperature range: -10℃ to 70℃
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seals: NBR (Nitrile) standard
- Weight: 0.48kg (excluding accessories)
- Dimensions: 100mm(L) × 34mm(W) × 34mm(H)
- Protection class: IP54 (standard sealing)
- Piston speed: 50–700mm/s
High-precision stopping cylinder with integrated shock absorption, featuring a space-saving design for precision positioning tasks. The TWQ20X10SB's dual piston guide structure ensures minimal rotational play (±0.5° max) during operation. Requires filtered air (5-50μm) with ISO VG32 lubricator oil recommended.
- Workpiece positioning in CNC rotary tables
- Tooling fixture locking in machining centers
- Conveyor flow control gates
- PCB board clamping in SMT equipment
- Robotic arm end effector positioning
Installation guidelines:
Maintain 0.5mm minimum clearance between stopper rod and target surface during setup.
For vertical installations, use counterbalance valves when handling loads >2kg.
Lubricate guide shafts monthly in high-cycle applications (>500,000 cycles/year).
| Property | Property Value |
|---|---|
| sku | TWQ20X10SB |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <10mm> |
| Blocking Method | Flat Cylinder |
