Airtac TWQ Stopper Cylinder TWQ20X10SC
1. Compliant with JIS standards;
2. Reinforced piston rod design effectively enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations. Hydraulic shock absorber option delivers superior cushioning performance;
4. Lever-type roller mechanism incorporates self-locking device to prevent rebound pushback from blocked objects;
5. Comprehensive series and specifications available for diverse application needs.
Category: Stopper Cylinder | Brand: AIRTAC | Series: TWQ
AirTAC TWQ Series Stopper Cylinder TWQ20X10SC Technical Details
- Model: TWQ20X10SC
- Type: Single-acting spring return stopper cylinder
- Bore size: 20mm
- Stroke: 10mm (±1mm adjustable)
- Operating pressure: 0.1-0.8 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer
- Port size: M5x0.8 (1/8" NPT optional)
- Rod thread: M6x1.0
- Body material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Weight: 0.48kg ±3%
- Dimensions: 100mm(L) × 40mm(W) × 40mm(H)
- ISO standard: 6432
- Mounting type: Front flange (MF1) with 4xM5 holes
- Repeat accuracy: ±0.2mm
High-precision stopper cylinder with integrated shock absorption, designed for precise workpiece positioning in automated systems. Features anti-rotation mechanism and IP54-rated construction for dust/moisture resistance. The hardened stainless steel guide rod ensures minimal wear during high-cycle operations (up to 1.5 million cycles).
- Conveyor line product positioning in packaging machinery
- PCB board clamping in electronics assembly
- Parts orientation control in automotive assembly robots
- Precision stopping mechanisms in pharmaceutical blister packaging
- Workpiece alignment in CNC machine tool loaders
Installation guidelines:
Maintain 0.5-1mm clearance between stopper tip and target surface during setup.
Lubricate with ISO VG32 hydraulic oil monthly. Avoid side-load forces exceeding 15N.
For vertical mounting, use auxiliary support brackets (sold separately).
| Property | Property Value |
|---|---|
| sku | TWQ20X10SC |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <10mm> |
| Blocking Method | Round Type |
