Airtac TWQ Stopper Cylinder TWQ20X15SR
1. Compliant with JIS standards;
2. Reinforced piston rod design effectively enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations. Hydraulic shock absorber option delivers superior cushioning performance;
4. Lever-type roller mechanism incorporates self-locking device to prevent rebound pushback from blocked objects;
5. Comprehensive series and specifications available for diverse application needs.
Category: Stopper Cylinder | Brand: AIRTAC | Series: TWQ
AirTAC TWQ Series Blocking Cylinder TWQ20X15SR Technical Specifications
- Model: TWQ20X15SR
- Type: Compact profile mechanical stop cylinder
- Bore size: Ø20mm
- Stroke: 15mm ±0.5mm
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -10℃ to 80℃
- Cushioning: Adjustable rubber bumper (both ends)
- Mounting type: Standard NAMUR pattern with M5 threaded holes
- Rod thread: M6×1.0 external thread
- Body material: Anodized aluminum alloy (AL6063-T5)
- Seal material: Nitrile butadiene rubber (NBR)
- Weight: 0.62kg ±3%
- Dimensions: 106mm(L) × 32mm(W) × 32mm(H)
- Protection rating: IP54 (standard), IP67 optional
- Repeat positioning accuracy: ±0.1mm
- Max lateral load: 15N at full extension
- Accessories: Includes mounting brackets (PBT-20) and 2x cushion screws
Precision blocking cylinder with integrated mechanical stopper mechanism, featuring dual-position locking capability through pneumatic actuation. The TWQ20X15SR's hardened stainless steel guide rod and chromium-plated piston rod ensure wear resistance in high-cycle applications. Requires 5μm filtered air with ISO VG32 lubricator for optimal performance.
- Workpiece positioning in CNC pallet systems
- Precision stop mechanism for robotic welding fixtures
- Component alignment in semiconductor handling equipment
- Safety interlock in automated assembly lines
- Tooling plate clamping in modular production systems
Installation note:
Maintain 0.05-0.1mm clearance between stopper face and target surface during mounting.
Lubricate guide rod weekly with ISO VG68 grease in high humidity environments.
Avoid side-load exceeding 5N during operation.
| Property | Property Value |
|---|---|
| sku | TWQ20X15SR |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <15mm> |
| Blocking Method | Roller Type |
