Airtac TWQ Stopper Cylinder TWQ20X20SB
1. Compliant with JIS standards;
2. Reinforced piston rod design effectively enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations. Hydraulic shock absorber option delivers superior cushioning performance;
4. Lever-type roller mechanism incorporates self-locking device to prevent rebound pushback from blocked objects;
5. Comprehensive series and specifications available for diverse application needs.
Category: Stopper Cylinder | Brand: AIRTAC | Series: TWQ
AirTAC TWQ20X20SB Blocking Cylinder Specifications
- Model: TWQ20X20SB
- Type: Compact profile double-acting blocking cylinder
- Bore size: 20mm
- Stroke: 20mm (±1mm tolerance)
- Operating pressure: 0.1–0.8 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting style: Double bracket mounting
- Port size: M5x0.8 (standard), G1/8 optional
- Temperature range: -10℃ to 70℃
- Material:
- Cylinder tube: Hard anodized aluminum alloy
- Piston rod: Stainless steel (SUS304)
- Seals: NBR (nitrile rubber)
- Weight: 0.75kg (excluding accessories)
- Dimensions: 150mm(L) × 40mm(W) × 40mm(H)
- Repeat positioning accuracy: ±0.2mm
- Maximum lateral load: 15N
- Protection rating: IP54 (standard)
High-rigidity blocking cylinder with integrated shock absorption, featuring a dual-sensor slot design for precise position detection. The hardened piston rod and double lip seals ensure durability in high-cycle applications (up to 5 million cycles). Requires 5μm filtered compressed air with lubrication (ISO VG32 recommended).
- Workpiece positioning in CNC machine tool changers
- Carton alignment systems in packaging lines
- PCB clamping mechanisms in electronics assembly
- Pallet stoppers in automated storage systems
- Safety interlocks in robotic workcells
Installation notes:1. Maintain 0.5mm clearance between stopper and workpiece for shock absorption
2. Use anti-vibration washers when mounting on moving platforms
3. Lubricate every 500,000 cycles under continuous operation
4. Avoid side impact forces exceeding 30% of maximum lateral load capacity
| Property | Property Value |
|---|---|
| sku | TWQ20X20SB |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <20mm> |
| Blocking Method | Flat Cylinder |
