Airtac TWQ Stopper Cylinder TWQ20X20SC
1. Compliant with JIS standards;
2. Reinforced piston rod design effectively enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations. Hydraulic shock absorber option delivers superior cushioning performance;
4. Lever-type roller mechanism incorporates self-locking device to prevent rebound pushback from blocked objects;
5. Comprehensive series and specifications available for diverse application needs.
Category: Stopper Cylinder | Brand: AIRTAC | Series: TWQ
AirTAC TWQ20X20SC Stopper Cylinder Technical Details
- Model: TWQ20X20SC
- Type: Compact double-acting stopper cylinder
- Bore size: 20mm
- Stroke: 20mm (customizable 10-100mm)
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -10℃ to 80℃
- Piston speed: 50–800 mm/s
- Cushioning type: Adjustable rubber bumper
- Port size: M5x0.8 (standard) / NPT1/8 (optional)
- Mounting style: Basic fixed mount with 4xM5 threaded holes
- Rod material: Hard chrome-plated steel (S45C)
- Tube material: Anodized aluminum alloy
- Seal type: NBR seals (FKM available for high-temp)
- Weight: 340g ±5g
- Dimensions:
- Length (retracted): 100mm
- Width (body): 32mm
- Height (mounting base): 20mm
- Rod diameter: 8mm
- ISO standard: 6432 (compact cylinder specifications)
High-precision stopping cylinder with integrated shock absorption, designed for precision positioning in automated assembly lines. Features wear-resistant chromium plating and dual anti-rotation guides for stable vertical operation. Includes built-in magnet for position sensing compatibility (sensor sold separately). Requires 5μm filtered air with ISO 8573-1:2010 Class 3.2.3 standards.
- PCB board clamping in SMT machines
- Workpiece positioning in CNC rotary tables
- Safety door interlocks for injection molding
- Precision alignment in optical lens assembly
- Carton stopping in packaging conveyors
Installation guidelines:
Maintain 0.5mm minimum clearance between stopper rod and target surface.
Lubricate with ISO VG32 turbine oil during initial setup. Avoid side-load forces exceeding 15N.
| Property | Property Value |
|---|---|
| sku | TWQ20X20SC |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <20mm> |
| Blocking Method | Round Type |
