Airtac TWQ Stopper Cylinder TWQ20X20SR
1. Compliant with JIS standards;
2. Reinforced piston rod design effectively enhances impact resistance;
3. Fixed mounting height with multiple rod end configurations. Hydraulic shock absorber option delivers superior cushioning performance;
4. Lever-type roller mechanism incorporates self-locking device to prevent rebound pushback from blocked objects;
5. Comprehensive series and specifications available for diverse application needs.
Category: Stopper Cylinder | Brand: AIRTAC | Series: TWQ
AirTAC TWQ20X20SR Stopper Cylinder Specifications
- Model: TWQ20X20SR
- Type: Compact double-acting stopper cylinder
- Bore size: 20mm
- Stroke: 20mm
- Operating pressure: 0.1–0.8 MPa
- Piston material: Hard anodized aluminum alloy
- Rod material: Stainless steel (SUS304)
- Seal type: NBR rubber with wear-resistant ring
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable rubber bumper
- Mounting type: Standard SR series base (side-mount)
- Weight: 0.48kg ±2%
- Dimensions:
- Body length: 76mm
- Total stroke length: 96mm
- Mounting base width: 32mm
- Rod diameter: 8mm
High-precision mechanical stopper cylinder with integrated shock absorption, designed for precision positioning and workpiece retention in automated systems. Features anti-rotation mechanism for stable vertical/horizontal operation and T-slot mounting compatibility. Includes dust-resistant wiper seal for contaminated environments.
- CNC machine tool workpiece clamping
- Conveyor line positioning gates
- Robotic arm end-effector positioning
- Semiconductor wafer handling systems
- Packaging machine product alignment
Installation note:
Lubricate rod with ISO VG32 hydraulic oil before initial use.
Maintain 0.5mm minimum clearance between stopper face and target surface.
Maximum lateral load: 15N. For vertical mounting, use counterbalance valve.
| Property | Property Value |
|---|---|
| sku | TWQ20X20SR |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Self-locking Function | Non Self-locking |
| Stroke | <20mm> |
| Blocking Method | Roller Type |
